DELTA DORE TYDOM 1.0 Installation Instructions

28 29
EN
CONTENTSCONTENTSPACK COMPOSITION
- 5 X3D receivers for roller shuer 1 A max., TYXIA 5630
- 1 receiver switch to control auxiliary light, TYXIA 6610
- 1 transmier switch, TYXIA 2330
- 1 TYDOM 1.0 home automaon box and its connector
TYXIA 5630
TYDOM 1.0
TYXIA 6610
TYXIA 2330
1/ Installation 31
1.1 TYXIA 2330 transmitter switch 31
1.2 TYXIA 6610 transmitter switch 31
1.3 Receiver for TYXIA 5630 roller shutter 34
1.4 TYDOM 1.0 36
2/ Wireless association 38
2.1 Associate the TYXIA 2330 switch
with the TYXIA 5630 receivers 38
2.2 Associate the TYDOM application
with the TYXIA 5630 receivers 39
2.3 Associate the TYDOM application
with the TYXIA 6610 receiver switch 41
3/ Learning for the shutter travel time 43
4/ Installation conguration 44
4.1 Favourite position 45
5/ Troubleshooting 46
5.1 TYXIA 2330 transmitter switch 46
5.2 Signals and possible faults on the TYDOM 1.0 47
5.3 Summary of functions accessible using the button
of the TYXIA 5630 receiver 49
