1.3 RECEIVER FOR TYXIA 5630 ROLLER SHUTTER
Recommenda ons
• IMPORTANT: the control wires are not insulated
from the mains power supply. All connected
equipment must be marked CE and meet the
requirements of the low voltage devices as well as
assembly recommenda ons. Local control wires can
be extended up to 10 m
(separate from the 230 V).
• The roller shu er high and low stops must be set before the receiver is installed.
You can install the receiver for roller shu er in a ush-
mounted box behind a switch or control push-bu on or in
a sealed box inside the roller shu er, a safe distance from
metal parts.
Connec on instruc ons for terminals 1 2 3 4
- Strip the wires while respec ng the strip length
speci ed on the product.
- Push the wire fully into the terminal.
• Solid wires • Stranded wires
0,75 - 1,5 mm
Ø
2
1/ INSTALLATION
Connec on instruc ons for IN1 - COM - IN2 terminals
Use the wires supplied.
Push the wire fully into the terminal.
Connec on
- Connect the motor control wires to terminals 3 and 4
(motor lowering control wire to terminal 3, raising control wire to terminal 4).
- Connect the switch to the IN1 - COM - IN2 terminals.
- Connect the 230 V power supply to terminals 1 and 2.
- Switch the installa on power back on to con nue with the associa on opera on.
Use an electrically
isolated tool to
perform the ac ons
on the receiver
con gura on
bu on.
TYXIA
Switch o the installa on
power supply
1
2
3 4
1
2
1
2
3 4
Do not strip the wires when they are
connected to the product as you could
damage the internal connector.
2
7mm
0,5 mm
KY31A02
1
2
3 4
230 V~
IN1
COM
IN2
1 2 3 4
TYXIA
1 2 3 4
IN1
COM
IN2
IN1
COM
IN2
IN1
COM
1
2
3
1
2
1
2
Hold switch
Double push-bu on
Push bu on
230V~
Removal recommendaons
Switch o the power supply.
Use a 2.5 mm screwdriver to press on the buon
before removing the wire.
1
2
3 4
1
2
Removal recommendaons
Turn the wire while pulling on it.
1
2
1
2
3 4
