7 - English
1. Sander with 6" x 48" Sanding Belt
2. Sanding Disc Plate
3. Belt and Pulley Cover
4. 9" Sanding Disc
5. T-Wrench
6. Backstop
7. Disc Cover
8. Support Rod
9. Table Assembly
10. M6 x 12mm Socket Head Cap Screws (2)
11. M6 Flat Washer (4)
12. M6 Lock Washer (4)
13. M4.2 x 12mm Pan Head Tap Screw (3)
14. M6 x 55mm Socket Head Cap Screws (2)
15. M10 x 12mm Hex Set Screw (4)
EXTENSION CORDS
Use proper extension cords. Make
sure your extension cord is in good condition and
is a 3-wire extension cord which has a 3-prong
grounding type plug and matching receptacle which
will accept the machine’s plug. When using an
extension cord, be sure to use one heavy enough to
carry the current of the machine. An undersized cord
will cause a drop in line voltage, resulting in loss of
power and overheating. Fig. C, shows the correct
gauge to use depending on the cord length. If in
doubt, use the next heavier gauge. The smaller the
gauge number, the heavier the cord.
Fig. C
MINIMUM GAUGE EXTENSION CORD
RECOMMENDED SIZES FOR USE WITH STATIONARY ELECTRIC MACHINES
Ampere
Rating Volts
Total
Length of
Cord in
Feet
Gauge of Extension
Cord
0-6 120
up to
25 18 AWG
0-6 120 25-50 16 AWG
0-6 120 50-100 16 AWG
0-6 120 100-150 14 AWG
6-10 120
up to
25 18 AWG
6-10 120 25-50 16 AWG
6-10 120 50-100 14 AWG
6-10 120 100-150 12 AWG
10-12 120
up to
25 16 AWG
10-12 120 25-50 16 AWG
10-12 120 50-100 14 AWG
10-12 120 100-150 12 AWG
12-16 120
up to
25 14 AWG
12-16 120 25-50 12 AWG
12-16 120
GREATER THAN 50 FEET NOT RECOMMENDED
FOREWORD
The Delta 31-695 features a large 9" diameter abrasive disc that is perfect for sanding large curves or rounding out
sharp corners. The Delta 31-695 also features an adjustable 6" belt unit that can be operated vertically or horizontally
or at any angle in between.
FUNCTIONAL DESCRIPTION
CARTON CONTENTS
1
2
3
4
5
6
7
8
9
Fig. 1A
Fig. 1B
13
14
15
12
11
10
To Next Page
