Delta AS08AD-C User Manual

Chapter 10 Function Cards
10-7
10
10.2.7.3 Specifications
 System Specifications
Item
Specification
General
Device type
Master, Slave and RTU
Topology
Star and linear topologies are supported.
IP Settings
 When installed on AS300 PLC CPU, you can
only use HWCONFIG from ISPSoft for editing.
 When installed on AS00SCM-A and used for
RTU application, you can edit via software
or hardware.
 Software: Set the ID2 and FORMAT2 to
0x000 and use HWCONFIG from EIP Builder
for editing.
 Hardware: Use the ID2 and FORMAT2 to set
IP address to 192.168.1.X (X=1~254) or turn
ID2 and FORMAT2 to 0xFF to make it in
DHCP mode.
Availability
AS300 Series PLC
AS00SCM-A (available only for RTU mode)
Web
Max. connection number
8
Functions
View device information
Account management
AS-FEN02 firmware update
When installed in AS00SCM-A and in RTU mode,
the module monitoring is supported.
 MODBUS TCP Specifications (only available for CPU modules)
Item
Specification
General
Device type
Server, Client
MODBUS TCP
Server
Max. connection number
8
Max. data length/per
transmission
200 words
MODBUS TCP
Client
Max. connection number
8
Max. data length/per
transmission
200 words
Note: The connection numbers of Server and Client are counted separately.
 EtherNet/IP Specifications
Item
Specification
General
Device type
Adapter
CIP Network I/O
Connection
CIP connection number
8
TCP connection number
8 (Servers)
Requested Packet Interval
(RPI)
1 ms~1000ms
Max. Transmission Speed
10,000 pps
Max. data length/per
transmission
200 bytes
CIP Network
Explicit Message
Class 3
(Connected Type)
Total 8 (Servers)
(for both class 3 and UCMM connection types)
UCMM
