Chapter 10 Function Cards
10-9
10.2.7.5 SM/SR
Special Auxiliary Relays (SM)
SM Function
AS300 Series
AS200 Series
OFF
ON
STOP
RUN
RUN
STOP
Latched
Attribute
Default
Data exchange through AS-FEN02 enabled by ISPSoft.
SM1008
Connection 1 for data exchange through AS-FEN02
○ – OFF – – N R/W OFF
SM1009
Connection 2 for data exchange through AS-FEN02
○ – OFF – – N R/W OFF
SM1010
Connection 3 for data exchange through AS-FEN02
○ – OFF – – N R/W OFF
SM1011
Connection 4 for data exchange through AS-FEN02
○ – OFF – – N R/W OFF
SM1012
Connection 5 for data exchange through AS-FEN02
○ – OFF – – N R/W OFF
SM1013
Connection 6 for data exchange through AS-FEN02
○ – OFF – – N R/W OFF
SM1014
Connection 7 for data exchange through AS-FEN02
○ – OFF – – N R/W OFF
SM1015
Connection 8 for data exchange through AS-FEN02
○ – OFF – – N R/W OFF
SM1016
Successful data exchange connection 1 through AS-
○ – OFF – – N R OFF
SM1017
Successful data exchange connection 2 through AS-
○ – OFF – – N R OFF
SM1018
Successful data exchange connection 3 through AS-
○ – OFF – – N R OFF
SM1019
Successful data exchange connection 4 through AS-
○ – OFF – – N R OFF
SM1020
Successful data exchange connection 5 through AS-
○ – OFF – – N R OFF
SM1021
Successful data exchange connection 6 through AS-
○ – OFF – – N R OFF
SM1022
Successful data exchange connection 7 through AS-
○ – OFF – – N R OFF
SM1023
Successful data exchange connection 8 through AS-
○ – OFF – – N R OFF
SM1024
Error in data exchange connection 1 through AS-
○ – OFF – – N R OFF
SM1025
Error in data exchange connection 2 through AS-
○ – OFF – – N R OFF
SM1026
Error in data exchange connection 3 through AS-
○ – OFF – – N R OFF
SM1027
Error in data exchange connection 4 through AS-
○ – OFF – – N R OFF
SM1028
Error in data exchange connection 5 through AS-
○ – OFF – – N R OFF
SM1029
Error in data exchange connection 6 through AS-
○ – OFF – – N R OFF
