Chapter 09 SpecificationsCP2000
9-5
9-3 575V Series
Frame A B
Model VFD_ _ _ _CP53A-21 015 022 037 055 075 110 150
*Out
ut ratin
ight duty
Rated output capacity [kVA] 3 4.3 6.7 9.9 12.1 18.6 24.1
Rated output current [A] 3 4.3 6.7 9.9 12.1 18.7 24.2
Applicable motor output [kW] 1.5 2.2 3.7 5.5 7.5 11 15
Applicable motor output [HP] 2 3 5 7.5 10 15 20
Normal
dut
Rated output capacity [kVA] 2.5 3.6 5.5 8.2 10 15.4 19.9
Rated output current [A] 2.5 3.6 5.5 8.2 10 15.4 20
Applicable motor output [kW] 0.75 1.5 2.2 3.7 5.5 7.5 11
Applicable motor output [HP] 1 2 3 5 7.5 10 15
Carrier frequency [kHz] 2–15 (Default: 4)
In
ut ratin
Input current [A]
Light duty 3.8 5.4 10.4 14.9 16.9 21.3 26.3
Normal duty 3.1 4.5 7.2 12.3 15 18 22.8
Rated voltage / Frequency
3-phase, 525–600 V
AC
[-15%– +10%]，50/60 Hz
Operating voltage range 446–660 V
C
Frequency tolerance 47–63 Hz
Efficiency [%] 97 98
Power factor > 0.98
Weight [Kg] 3± 0.3 4.8± 1
Cooling method Natural cooling Fan cooling
Braking chopper Frame A–B: Built-in
DC choke Frame A–B: Optional
NOTE
The carrier frequency is default. Increasing the carrier frequency requires a reduction in current. Please refer to Chapter
9-7 Derating Curve of Ambient Temperature.
Select the AC motor drive with capacity one grade larger for the impact load application.
Refer to Chapter 9-6 Specification for Operation Temperature and Protection Level for the protection level of each model.
* The default setting is Light Duty, you can select Normal Duty and Light Duty by setting Pr.00-16.
