Chapter 11 Summary of Parameter SettingsCP2000
11-29
07 Special Parameters
Pr. Parameter Name Setting Range Default
07-00 Built-in Software brake level
230V: 350.0–450.0 V
DC
460V: 700.0–900.0 V
DC
575V: 850.0–1116.0 V
DC
690V: 939.0–1318.0 V
DC
370.0
740.0
895.0
1057.0
07-01 DC brake current level 0–100% 0
07-02 DC brake time at run 0.0–60.0 sec. 0.0
07-03 DC brake time at stop 0.0–60.0 sec. 0.0
07-04 DC brake frequency at stop 0.00–599.00 Hz 0.00
07-05 Voltage increasing gain 1–200% 100
07-06
Restart after momentary power
loss
0: Stop operation
1: Speed tracking by speed before the power loss
2: Speed tracking by minimum output frequency
0
07-07 Allowed power loss duration 0.0–20.0 sec. 2.0
07-08 Base block time 0.0–5.0 sec. (Depending on the model power)
Depending
on the
model
power
07-09 Current limit of speed tracking
20–200% (100% corresponds to the light-load rated
current of the drive)
100
07-10 Restart after fault action
0: Stop operation
1: Speed tracking by current speed
2: Speed tracking by minimum output frequency
0
07-11
Number of times of restart after
fault
0–10 0
07-12 Speed tracking during start-up
0: Disable
1: Speed tracking by maximum output frequency
2: Speed tracking by motor frequency at start
3: Speed tracking by minimum output frequency
0
07-13 dEb function selection
0: Disable
1: dEb with auto acceleration / deceleration, the drive
does not output the frequency after the power is
restored.
2: dEb with auto-acceleration / auto-deceleration, the
drive outputs the frequency after the power is
restored.
0
07-15 Dwell time at acceleration 0.00–600.00 sec. 0.00
07-16 Dwell frequency at acceleration 0.00–599.00 Hz 0.00
07-17 Dwell time at deceleration 0.00–600.00 sec. 0.00
07-18 Dwell frequency at deceleration 0.00–599.00 Hz 0.00
07-19 Fan cooling control
0: Fan always ON
1: Fan is OFF after the AC motor drive stops for one
minute
2: Fan is ON when AC motor drive runs; fan is OFF
when AC motor drive stops
0
