Delta CP2000 Series User Manual

Chapter 11 Summary of Parameter SettingsCP2000
11-17
Pr. Parameter Name Setting Range Default
6: Power factor
7: Power
9: AVI1%
10: ACI%
11: AVI2%
20: CANopen analog output
21: RS-485 analog output
22: Communication card analog output
23: Constant voltage output
 03-21 Analog output gain 1 (AFM1) 0.0–500.0% 100.0
 03-22
Analog output 1 in REV direction
(AFM1)
0: Absolute value of output voltage
1: Reverse output 0 V; forward output 0–10 V
2: Reverse output 5–0 V; forward output 5–10 V
0
 03-24 Analog output gain 2 (AFM2) 0.0–500.0% 100.0
 03-25
Analog output 2 in REV direction
(AFM2)
0: Absolute value of output voltage
1: Reverse output 0 V; forward output 0–10 V
2: Reverse output 5–0 V; forward output 5–10 V
0
 03-27 AFM2 output bias -100.00–100.00% 0.00
 03-28 AVI1 terminal input selection
0: 0–10 V
1: 0–20 mA
2: 4–20 mA
0
 03-29 ACI terminal input selection
0: 4–20 mA
1: 0–10 V
2: 0–20 mA
0
03-30
PLC analog output terminal
status
Monitor the status of PLC analog output terminals
Read
only
 03-31 AFM2 output selection
0: 0–20 mA output
1: 4–20 mA output
0
 03-32 AFM1 DC output setting level
0.00–100.00% 0.00
 03-33 AFM2 DC output setting level
03-34 AFM1 output selection
0: 0–20 mA output
1: 4–20 mA output
0
 03-35 AFM1 filter output time
0.00–20.00 sec. 0.01
 03-36 AFM2 filter output time
 03-44
Multi-function MO output by AI
level source
0: AVI1
1: ACI
2: AVI2
0
 03-45 AI upper level -100.00–100.00% 50.00
 03-46 AI lower level -100.00–100.00% 10.00
 03-50 Analog input curve selection
0: Regular curve
1: Three-point curve of AVI1
2: Three-point curve of ACI
3: Three-point curve of AVI1 & ACI
4: Three-point curve of AVI2
5: Three-point curve of AVI1 & AVI2
6: Three-point curve of ACI & AVI2
7: Three-point curve of AVI1 & ACI & AVI2
7
