Delta CP2000 Series User Manual

Chapter 12 Description of Parameter SettingsCP2000
12.1-00-1
Chapter 12 Description of Parameter Settings
12-1 Description of parameter settings
00 Drive Parameters
 This parameter can be set during operation.
Identity Code of the AC Motor Drive
Default: Read only
Settings Read Only
Display AC Motor Drive Rated Current
Default: Read only
Settings Read Only
 Pr.00-00 displays the identity code of the AC motor drive. Using the following specification table to
check if Pr.00-01 setting is the rated current of the AC motor drive. Pr.00-01 corresponds to the
identity code of the AC motor drive (Pr.00-00).
 The default is the rated current for light load. Set Pr.00-16 to 1 to display the rated current for
normal load.
230V Series
Frame A B
kW 0.75 1.5 2.2 3.7 5.5 7.5 11 15
HP 1 2 3 5 7.5 10 15 20
Identity code 4 6 8 10 12 14 16 18
Rated current for
light load [A]
5 7.5 10 15 21 31 46 61
Rated current for
normal load [A]
3 5 8 11 17 25 33 49
Frame C D E
kW 18.5 22 30 37 45 55 75 90
HP 25 30 40 50 60 75 100 125
Identity code 20 22 24 26 28 30 32 34
Rated current for
light load [A]
75 90 105 146 180 215 276 322
Rated current for
normal load [A]
65 75 90 120 146 180 215 255
460V Series
Frame A B C
kW 0.75 1.5 2.2 3.7 4.0 5.5 7.5 11 15 18.5 22 30 37
HP 1 2 3 5 5 7.5 10 15 20 25 30 40 50
Identity code 5 7 9 11 93 13 15 17 19 21 23 25 27
Rated current for
light load [A]
3 4.2 5.5 8.5 10.5 13 18 24 32 38 45 60 73
Rated current for
normal load [A]
2.8 3.0 4.0 6.0 9.0 10.5 12 18 24 32 38 45 60
