Delta CP2000 Series User Manual

Chapter 2 InstallationCP2000
2-5
2-2 Flow and Power Dissipation
Air flow rate for cooling Power Dissipation
Model No.
Flow Rate [cfm] Flow Rate [m
3
/hr] Power Dissipation [watt]
External Internal Total External Internal Total
Loss External
(Heat Sink)
Internal Total
VFD007CP23A-21 - - - - - - 40 31 71
VFD015CP23A-21 - - - - - - 61 39 100
VFD022CP23A-21 14 - 14 24 - 24 81 45 126
VFD037CP23A-21 14 - 14 24 - 24 127 57 184
VFD055CP23A-21 10 - 10 17 - 17 158 93 251
VFD075CP23A-21 40 14 54 68 24 92 291 101 392
VFD110CP23A-21 66 14 80 112 24 136 403 162 565
VFD150CP23A-21 58 14 73 99 24 124 570 157 727
VFD185CP23A-21 166 12 178 282 20 302 622 218 840
VFD220CP23A-21 166 12 178 282 20 302 777 197 974
VFD300CP23A-21 146 12 158 248 20 268 878 222 1100
VFD370CP23A-00/
VFD370CP23A-21
179 30 209 304 51 355 1271 311 1582
VFD450CP23A-00/
VFD450CP23A-21
179 30 209 304 51 355 1550 335 1885
VFD550CP23A-00/
VFD550CP23A-21
228 73 301 387 124 511 1762 489 2251
VFD750CP23A-00/
VFD750CP23A-21
228 73 301 387 124 511 2020 574 2594
VFD900CP23A-00/
VFD900CP23A-21
246 73 319 418 124 542 2442 584 3026
VFD007CP43A/
VFD007CP4EA-21
- - - - - -
35 32 67
VFD015CP43B/
VFD015CP4EB-21
- - - - - -
48 39 87
VFD022CP43B/
VFD022CP4EB-21
- - - - - -
64 52 116
VFD037CP43B/
VFD037CP4EB-21
14 - 14 24 - 24 103 77 180
VFD040CP43A/
VFD040CP4EA-21
10 - 10 17 - 17 124 81 205
VFD055CP43B/
VFD055CP4EB-21
10 - 10 17 - 17 142 116 258
VFD075CP43B/
VFD075CP4EB-21
10 - 10 17 - 17 205 129 334
VFD110CP43B/
VFD110CP4EB-21
40 14 54 68 24 92 291 175 466
VFD150CP43B/
VFD150CP4EB-21
66 14 80 112 24 136 376 190 566
VFD185CP43B/
VFD185CP4EB-21
58 14 73 99 24 124 396 210 606
VFD220CP43A/
VFD220CP4EA-21
99 21 120 168 36 204 455 358 813
VFD300CP43B/
VFD300CP4EB-21
99 21 120 168 36 204 586 410 996
VFD370CP43B/
VFD370CP4EB-21
126 21 147 214 36 250 778 422 1200
VFD450CP43S-00/
VFD450CP43S-21
179 30 209 304 51 355 1056 459 1515
VFD550CP43S-00/
VFD550CP43S-21
179 30 209 304 51 355 1163 669 1832
VFD750CP43B-00/
VFD750CP43B-21
179 30 209 304 51 355 1407 712 2119
VFD900CP43A-00/
VFD900CP43A-21
186 30 216 316 51 367 1787 955 2742
VFD1100CP43A-00/
VFD1100CP43A-21
257 73 330 437 124 561 2112 1084 3196
VFD1320CP43B-00/
VFD1320CP43B-21
223 73 296 379 124 503 2597 1220 3817
VFD1600CP43A-00/ 224 112 336 381 190 571 3269 1235 4504
