Load Cell Module DVP02LC-SL
DVP-PLC Operation Manual
24
Gross/Net:
Corresponds to the value in CR#7. Scroll down to select displaying the gross weight or net weight.
Tare weight:
Corresponds to the value in CR#8 and CR#9. Enter the tare weight here, or click “Read TW” to set
it up. The range is -32,768 to 32,767, and the default setting is 0.
Read TW:
Corresponds to the value in CR#6. Click “Read TW” to take the average value of each channel as
the tare weight.
Average times:
Corresponds to the value in CR#10 and CR#11. The range is 1 to 100, and the default setting is
10.
Maximum weight:
Corresponds to the value in CR#35 and CR#36. Enter the maximum weight here. When the
measured value exceeds this weight, an error status will be displayed. The range is -32,768 to
32,767, and the default setting is 32,767.
Unit of measurement:
Corresponds to CR#22 and CR#23 for CH1 and CR#24 and CR#25 for CH2. You can enter a unit
here for the user’s reference. Maximum 4 characters are allowed in this column. The default
setting is Kg.
Standstill times:
The times of standstill checks, corresponding to the value in CR#16 and CR#17. Enter the times
here. The range is 1 to 500, and the default setting is 5.
Standstill range:
The range for standstill check, corresponding to the value in CR#18 and CR#19. Enter the range
(1 to 10,000) here. The default setting is 10.
Zero band:
The upper and lower limits for the zero point check. The upper limit for CH1 corresponds to the
value in CR#37, and the lower limit corresponds to the value in CR#39. The upper limit for CH2
corresponds to the value in CR#38, and the lower limit corresponds to the value in CR#40. When
the weight measured is within the range, the status code will be set to “zero bit＂ indicating that it
is currently in empty status now. Enter the upper and lower limits here. The range is K-32,768 to
K32,767, and the default setting is -10 to 10.
Filter ratio setting
The filter percentage, corresponding to the value in CR#43 and CR#44. The range is 1 to 5. The
average weight after being filtered will be displayed as the filter average values for CH1 and CH2
on the toolbar, or you can check CR#45 and CR#46 for the filter average value. The default setting
is 2.
