Delta E Series Software Instructions

伺服壓床簡易配方設定軟體操作說明
23
4. Communications Data Capture
4.1
RS-485 connection information
The RS-485 station number can be set through [Euipment Parameters]->[COMM.], please refer to the
table below for other information
Baud rate Date Length Parity Stop Bit Mode
9600 7 E 1 RTU
4.2 Modbus connection information
The servo press can retrieve the following data in real time via Modbus TCP (default IP: 192.168.1.5 Port:
502)
Item Modbus Delta PLC
Status
Recipe number
0x13BF D959
Real-time position
0x10C8 D200
Real-time force
0x10CA D202
Status*
0x10CE D206
Pressing result
Pressing position
0x10D2 D210
Pressing result
0x1107 D263
pressing force
0x10D4 D212
Standby time
0x10D6 D214
Pressing time
0x10D8 D216
Production time
0x10DA D218
Total Amount
0x10DE D222
Pass Amount
0x10E0 D224
Fail Amount
0x10E2 D226
* Real-time status: 0-not activated; 1-activating; 2-activation complete and waiting; 3-pressing; 4-pressing OK;
5-NG, force is greater than the maximum limit; 6-NG, force is less than the minimum limit; 7-NG, position is
greater than the maximum limit; 8-NG, position is less than the minimum limit
** If you use Modbus communications, please confirm the correctness of the address, and it is strictly forbidden
to write in the relevant address
