Chapter 11 Summary of Parameter SettingsMS300
229
05 Motor Parameters
Pr.
Explanation
Settings
Default
05-00
Motor Parameter
Auto-Tuning
0: No function
1: Dynamic test for induction motor (IM)
2: Static test for induction motor (IM)
5: Rolling auto-tuning for PM (IPM / SPM)
12: FOC sensorless inertia estimation
13: High frequency stall test for PM
0
05-01
Full-Load Current for
Induction Motor 1 (A)
10–120% of the drive’s rated current
Depending
on the
model
power

05-02
Rated Power for Induction
Motor 1 (kW)
0.00–655.35 kW
Depending
on the
model
power

05-03
Rated Speed for Induction
Motor 1 (rpm)
0–xxxxx rpm (Depending on the motor’s number of poles)
1710 (60 Hz, 4 poles); 1410 (50 Hz, 4 poles)
Depending
on the
motor’s
number of
poles
05-04
Number of Poles for
Induction Motor 1
2–20
4
05-05
No-Load Current for
Induction Motor 1 (A)
0.00–Pr.05-01 default
Depending
on the
model
power
05-06
Stator Resistance (Rs) for
Induction Motor 1
0.000–65.535 
Depending
on the
model
power
05-07
Rotor Resistance (Rr) for
Induction Motor 1
0.000–65.535 
0.000
05-08
Magnetizing Inductance
(Lm) for Induction Motor 1
0.0–6553.5 mH
0.0
05-09
Stator Inductance (Lx) for
Induction Motor 1
0.0–6553.5 mH
0.0
05-13
Full-Load Current for
Induction Motor 2 (A)
10–120% of the drive’s rated current
Depending
on the
model
power

05-14
Rated Power for Induction
Motor 2 (kW)
0.00–655.35 kW
Depending
on the
model
power

05-15
Rated Speed for Induction
Motor 2 (rpm)
0–xxxxx rpm (Depending on the motor’s number of poles)
1710 (60 Hz, 4 poles); 1410 (50 Hz, 4 poles)
Depending
on the
motor’s
number of
poles
05-16
Number of Poles for
Induction Motor 2
2–20
4
05-17
No-Load Current for
Induction Motor 2 (A)
0.00–Pr.05-13 default
Depending
on the
model
power
