Chapter 12 Descriptions of Parameter SettingsMS300
343
04 Multi-Step Speed Parameters
You can set this parameter during operation.
Use the multi-function input terminals (refer to settings 1–4 of Pr.02-01–02-07 Multi-function
Input Command) to select the multi-step speed command (the maximum is 15
th
step speed).
Pr.04-00 to Pr.04-14 sets the multi-step speed (frequency) as shown in the following diagram.
The external terminal/digital keypad/communication controls the RUN and STOP commands
with Pr.00-21.
You can set each multi-step speed between 0.00–599.00 Hz during operation.
Explanation for the timing diagram of the multi-step speed and external terminals
The related parameter settings are:
1. Pr.04-00–Pr.04-14: sets the 1
st
–15
th
multi-step speed (to set the frequency of each step
speed).
2. Pr.02-01–Pr.02-07: sets the multi-function input terminals (multi-step speed command 1–4).
Related parameters:
Pr.01-22 JOG frequency setting
Pr.02-01 multi-function input command 1 (MI1)
Pr.02-02 multi-function input command 2 (MI2)
Pr.02-03 multi-function input command 3 (MI3)
Pr.02-04 multi-function input command 4 (MI4)
