Delta RPI-M15A Quick Installation Guide

17
Quick installation guide for RPI M15A M20A inverters
Setting the inverter ID
IfyourPVplantcontainsmultipleinverters,adifferentinverterIDhastobesetforeachoftheinverters.
The inverter ID is needed to identify each inverter. For a description of the RS485 connection, see “Con-
nectingtoadataloggerviaRS485(optional)”,p.11.
1. Whenthedefaultinformationisdisplayed,pressthebutton
ESC
toopenthemainmenu.Otherwise,repeatedlypress
thebutton
ESC
until the main menu is displayed.
20
15
10
5
0
4 8 12 16 20 24
P(w)
Runtime: 8.2Hrs Power: 12103W
On Grid
21. Jun 2013 09:30
E-Today: 47kWh
2. Usethebuttons and to select Settings.
Toconrmyourselection,pressthebutton
ENT
.
E-TodayE-Today
Power Meter
Energy Log
Event Log
Inverter Information
Settings
Operation Data
21. Jun 2013 09:30
Menu
3. Usethebuttons and to select Install Settings.
Toconrmyourselection,pressthebutton
ENT
.
Personal SettingsPersonal Settings
Coefficient SettingsCoefficient Settings
Install Settings
Active/Reactive Power Control
FRT
21. Jun 2013 09:30
Settings
4. Themenuisprotectedbypassword5555.Usethebuttons
and to set each digit.
Toconrmadigit,pressthebutton
ENT
.
33 3 3 ENT
21. Jun 2013 09:30
Password
5. Usethebuttons and to select Inverter-ID.
Toconrmyourselection,pressthebutton
ENT
.
Inverter ID
Insulation
RCMU
Country
Grid Settings
Country
Grid Settings
[
[
]
]
001
ON
[ ]Yes / No
001001
England
21. Jun 2013 09:30
Install Settings
6. TheIDisnowhighlighted.Usethebuttons and to
change the value.
Toconrmyoursetting,pressthebutton
ENT
.
Inverter ID
Insulation
RCMU
Country
Grid Settings
Country
Grid Settings
[
[
]
]
001
ON
[ ]Yes / No
002
England
21. Jun 2013 09:30
Install Settings
