Operation and installation manual SOLIVIA 5.0 EU G3
9 Technical data
* The maximum AC power value indicates the power
an inverter might be able to deliver. However, such a
maximum AC power may not necessarily be achieved.
** AC voltage and frequency range will be programmed
according to the individual country requirements.
INPUT (DC)
Max. recommended PV
power
6000 W EU (5320 W DE /
5250 W BE)
Nominal power 5500 W EU (4850 W DE / BE)
Voltage range 125 ... 540 V
MPP range 150 ... 450 V
Full power MPP range 150 ... 450 V
Nominal current 17.2 A
Max. current 32.0 A
Stand-by power < 0.2 W
OUTPUT (AC)
Max. power *
5240 W EU (5060 W DE /
5000 W BE)
Nominal power
5000 W EU (4600 W DE / BE)
Voltage range ** 184 ... 264 V
Nominal current 22.0 A
Max. current 27.2 A
Nominal frequency 50 Hz
Frequency range ** 47.0 ... 52.0 Hz
Power factor > 0.99 @ nominal power
Total harmonic
distortion (THD)
< 4 % @ nominal power
GENERAL SPECIFICATION
Model name SOLIVIA 5.0 EU G3
Max. efficiency 95.6 %
Efficiency EU 94.6 %
Operating
temperature
-25 ... +60 °C
Storage temperature -25 ... +80 °C
Humidity 0 ... 98 %
MECHANICAL DESIGN
Size (L x W x D) 510 x 410 x 180 mm
Weight 32.0 kg
Cooling Convection
AC connector Wieland RST25i3S
DC connector pairs 4 Tyco Solarlok
Communication
interfaces
2 Harting RJ45 / RS485
DC disconnector -
Display LCD; 3 LEDs
STANDARDS / DIRECTIVES
Protection degree IP65
Safety class 1
Configurable trip
parameters
Yes
Insulation monitoring Yes
Overload behavior
Current limitation;
power limitation
Safety
EN60950-1; EN50178;
IEC62103; IEC62109-1 / -2
Anti-islanding
protection
VDE 0126-1-1; RD 1663;
ENEL G.L. 12/2008; EN 50438
EMC
EN61000-6-2; EN61000-6-3;
EN61000-3-2; EN61000-3-3
