Delta VFD007EL43W User Manual

Appendix A Specifications  VFD-EL-W
A-2
A1. 230V 1φ Series
Model
Number
VFD□□□EL21W (-1)
002 004 007 015 022
Max. Applicable Motor
Output (kW)
0.2 0.4 0.75 1.5 2.2
Max. Applicable Motor
Output (HP)
0.25 0.5 1.0 2.0 3.0
Output Rating
Rated Output
Capacity (kVA)
0.6 1.0 1.6 2.9 4.2
Rated Output
Current (A)
1.6 2.5 4.2 7.5 11.0
Maximum Output
Voltage (V)
Three-phase Proportional to Input Voltage
Output Frequency
(Hz)
0.1–400
Carrier
Frequency
(kHz)
2–12 (default: 8)
Input Rating
Rated Input Current
(A)
4.9 6.5 9.3 15.7 24.0
Rated
Voltage/Frequency
One-phase, 200–240 V, 50 / 60 Hz
Voltage Tolerance

10% (180–264 V)
Frequency
Tolerance

5% (47–63 Hz)
Cooling Method
Convective Cooling
Fan Cooling
Weight (kg)
1.0
1.0
1.
0
1.4
1.4
A2. 460V 3φ Series
Model
Number
VFD□□□EL43W (-1)
004 007 015 022 040
Max. Applicable Motor Output
(kW)
0.4 0.75 1.5 2.2 4.0
Max. Applicable Motor Output
(HP)
0.5 1.0 2.0 3.0 5.5
Output Rating
Rated Output Capacity
(kVA)
1.2 2.0 3.3 4.4 7.4
Rated Output Current (A)
1.5 2.5 4.2 5.5 9.0
Maximum Output Voltage
(V)
Three-phase Proportional to Input Voltage
Output Frequency (Hz)
0.1
–
400
Carrier Frequency
(kHz)
2
–
12 (default: 8)
Input
Rating
Rated Input Current (A)
1.8
3.2
4.3
7.1
10.0
Rated Voltage/Frequency
Three
-
phase, 380
–
480V, 50 / 60Hz
Voltage Tolerance

10% (342–528 V)
Frequency Tolerance

5% (47–63 Hz)
Cooling Method
Convective Cooling
Fan Cooling
Weight (kg)
1.0
1.0
1.0
1.4
1.4
