Delta VFD040EL43W User Manual

Chapter 4 Parameters  VFD-EL-W
4-7
Parameter Function Setting Default Customer
02.08
Accel./ Decel. Rate of Change
of UP/DOWN Operation with
Constant Speed
0.01–10.00 Hz / 2ms 0.01
02.09
Second Frequency Command
Source
0: Digital keypad UP/DOWN keys or Multi-
function Inputs UP/DOWN.
1: 0–10V from AVI
2: 4–20 mA from ACI
3: RS-485 (RJ45) communication
4: Digital keypad potentiometer
0
02.10
Combining the First and
Second Master Frequency
Commands
0: First Master Frequency Command Only
1: First Master Frequency Command+ Second
Master Frequency Command
2: First Master Frequency Command -
Second Master Frequency Command
0
02.11 Keypad Frequency Command 0.00–400.0 Hz 60.00
02.12
Communication Frequency
Command
0.00–400.0 Hz 60.00
02.13
Saving Keypad or
Communication Frequency
Command Selection
0: Save Keypad & Communication Frequency
0 1: Save Keypad Frequency Only
2: Save Communication Frequency Only
02.14
Initial Frequency Selection
(for
keypad & RS-485)
0: Current Frequency Command
0 1: Zero Frequency Command
2: Refer to Pr.02.15 to set up
02.15
Initial Frequency Setting (for
keypad & RS-485)
0.00–400.0 Hz 60.00
02.16
Display the Master Frequency
Command Source
Read Only
1: bit0=1: First Master Frequency Source
(Pr.02.00)
2: bit1=1: Second Master Frequency Source
(Pr.02.09)
4: bit2=1: Multi-function input
Read
only
02.17
Display the Operation
Command Source
Read Only
1: bit0=1: Digital Keypad
2: bit1=1: RS-485 communication
4: bit2=1: External Terminal (MI1)
8: bit3=1: Multi-function input
Read
only
02.18 User-defined Value 2 Setting 0–Pr.00.13 0
02.19 User-defined Value 2 0–9999
Read
only
