Chapter 12 Description of Parameter SettingsME300
12.1-09-10
Content Register Function
2200H
Display output current (A). When current is higher than 655.35,
it shifts the decimal as (XXX.X A). The decimal can refer to
High byte of 211F.
2201H Display counter value (c)
2202H Actual output frequency (XXXXX Hz)
2203H DC BUS voltage (XXX.X V)
2204H Output voltage (XXX.X V)
2205H Power angle (XXX.X)
2206H Display actual motor speed kW of U, V, W (XXXXX kW)
2207H
Display motor speed in rpm estimated by the drive (XXXXX
rpm)
2208H
Display positive / negative output torque in %, estimated by the
drive (+0.0: positive torque, -0.0: negative torque) (XXX.X%)
2209H Display PG feedback (see NOTE 1 in Pr.00-04)
220AH PID feedback value after enabling PID function (XXX.XX%)
220BH
Display signal of AVI analog input terminal, 0-10 V corresponds
to 0.00–100.00% (2.) (see NOTE 2 in Pr.00-04)
220CH
Display signal of ACI analog input terminal, 4–20 mA / 0–10 V
corresponds to 0.00–100.00% (2.) (as Pr.00-04 see NOTE 2)
220DH Reserved
220EH IGBT temperature of drive power module (XXX.X °C)
220FH Reserved
2210H
The status of digital input (ON / OFF), refer to Pr.02-12
(see NOTE 3 in Pr.00-04)
2211H
The status of digital output (ON / OFF), refer to Pr.02-18
(see NOTE 4 in Pr.00-04)
2212H The multi-step speed that is executing (S)
2213H
The corresponding CPU pin status of digital input (d.)
(see NOTE 3 in Pr.00-04)
2214H
The corresponding CPU pin status of digital output (O.)
(see NOTE 4 in Pr.00-04)
2219H Display times of counter overload (XXX.XX%)
221AH GFF (XXX.XX%)
221BH DC BUS voltage ripples (XXX.X V)
221DH Number of poles of a permanent magnet motor
221EH User page displays the value in physical measure
221FH Output value of Pr.00-05 (XXX.XX Hz)
2220H
Number of motor turns when drive operates (saves when drive
stops, and resets to zero when operating)
2221H
Operating position of the motor (saves when drive stops, and
resets to zero when operating)
2222H Reserved
2223H Control mode of the drive. 0: speed mode 1: torque mode
2224H Carrier frequency of the drive (XX kHz)
2225H Reserved
2226H
Drive status
bit 1–0 00b: No direction
01b: Forward
10b: Reverse
bit 3–2 01b: Drive ready
10b: Error
bit 4 0b: Motor drive did not output
1b: Motor drive did output
bit 5 0b: No alarm
1b: Alarm
2227H
Drive’s estimated output torque (positive or negative direction)
(XXXX Nt-m)
