Chapter 7 Optional AccessoriesME300
7-17
230V, 50–60 Hz / One-Phase - Normal Duty
Model
Rated
Current
[Arms]
Saturation
Current
[Arms]
Intput AC / DC
Reactor
[mH]
Intput AC / DC
reactor
Delta part #
Output AC
reactor
[mH]
Output AC
reactor
Delta part #
VFD1A6ME21ANNAA
VFD1A6ME21AFNAA
VFD1A6ME21ANSAA
VFD1A6ME21AFSAA
1.8 2.7 5.857 DR005D0585 2.54 DR005L0254
VFD2A8ME21ANNAA
VFD2A8ME21AFNAA
VFD2A8ME21ANSAA
VFD2A8ME21AFSAA
3.2 4.8 3.66 DR008D0366 2.54 DR005L0254
VFD4A8ME21ANNAA
VFD4A8ME21AFNAA
VFD4A8ME21ANSAA
VFD4A8ME21AFSAA
5 7.5 2.66 DR011D0266 2.54 DR005L0254
VFD7A5ME21ANNAA
VFD7A5ME21AFNAA
VFD7A5ME21ANSAA
VFD7A5ME21AFSAA
8.5 12.75 1.72 DR017D0172 1.15 DR011L0115
VFD11AME21ANNAA
VFD11AME21AFNAA
VFD11AME21ANSAA
VFD11AME21AFSAA
12.5 18.75 1.17 DR025D0117 0.746 DR017LP746
230V, 50–60 Hz / One-Phase - Heavy Duty
Model
Rated
Current
[Arms]
Saturation
Current
[Arms]
Intput AC / DC
Reactor
[mH]
Intput AC / DC
reactor
Delta part #
Output AC
reactor
[mH]
Output AC
reactor
Delta part #
VFD1A6ME21ANNAA
VFD1A6ME21AFNAA
VFD1A6ME21ANSAA
VFD1A6ME21AFSAA
1.6 3.2 5.857 DR005D0585 2.54 DR005L0254
VFD2A8ME21ANNAA
VFD2A8ME21AFNAA
VFD2A8ME21ANSAA
VFD2A8ME21AFSAA
2.8 5.6 3.66 DR008D0366 2.54 DR005L0254
VFD4A8ME21ANNAA
VFD4A8ME21AFNAA
VFD4A8ME21ANSAA
VFD4A8ME21AFSAA
4.8 9.6 2.66 DR011D0266 2.54 DR005L0254
VFD7A5ME21ANNAA
VFD7A5ME21AFNAA
VFD7A5ME21ANSAA
VFD7A5ME21AFSAA
7.5 15 1.72 DR017D0172 1.59 DR008L0159
VFD11AME21ANNAA
VFD11AME21AFNAA
VFD11AME21ANSAA
VFD11AME21AFSAA
11 22 1.17 DR025D0117 1.15 DR011L0115
230V, 50–60 Hz / Three-Phase - Normal Duty
Model
Rated
Current
[Arms]
Saturation
Current
[Arms]
Intput /
Output AC
Reactor
[mH]
Intput AC
reactor
Delta part #
Outtput AC
reactor
Delta part #
DC
Reactor
[mH]
DC reactor
Delta part #
VFD0A8ME23ANNAA
VFD0A8ME23ANSAA
1 1.5 2.536 DR005A0254 DR005L0254 5.857 DR005D0585
VFD1A6ME23ANNAA
VFD1A6ME23ANSAA
1.8 2.7 2.536 DR005A0254 DR005L0254 5.857 DR005D0585
VFD2A8ME23ANNAA
VFD2A8ME23ANSAA
3.2 4.8 2.536 DR005A0254 DR005L0254 5.857 DR005D0585
