Chapter 7 Optional AccessoriesME300
7-19
Model
Rated
Current
[Arms]
Saturation
Current
[Arms]
Intput /
Output AC
Reactor
[mH]
Intput AC
reactor
Delta part #
Outtput AC
reactor
Delta part #
DC
Reactor
[mH]
DC reactor
Delta part #
VFD7A3ME43ANNAA
VFD7A3ME43AFNAA
VFD7A3ME43ANSAA
VFD7A3ME43AFSAA
8.9 13.35 2.7 DR009A0270 DR009L0270 6.236 DR009D0623
VFD9A0ME43ANNAA
VFD9A0ME43AFNAA
VFD9A0ME43ANSAA
VFD9A0ME43AFSAA
10.5 15.75 2.315 DR010A0231 DR010L0231 5.345 DR010D0534
VFD13AME43ANNAA
VFD13AME43AFNAA
VFD13AME43ANSAA
VFD13AME43AFSAA
15.7 23.55 1.174 DR018A0117 DR018L0117 3.119 DR018D0311
VFD17AME43ANNAA
VFD17AME43AFNAA
VFD17AME43ANSAA
VFD17AME43AFSAA
20.5 30.75 0.881 DR024AP881 DR024LP881 3.119 DR018D0311
460V, 50–60 Hz / Three-Phase - Heavy Duty
Model
Rated
Current
[Arms]
Saturation
Current
[Arms]
Intput /
Output AC
Reactor
[mH]
Intput AC
reactor
Delta part #
Outtput AC
reactor
Delta part #
DC
Reactor
[mH]
DC reactor
Delta part #
VFD1A5ME43ANNAA
VFD1A5ME43AFNAA
VFD1A5ME43ANSAA
VFD1A5ME43AFSAA
1.5 3 8.102 DR003A0810 DR003L0810 18.709 DR003D1870
VFD2A7ME43ANNAA
VFD2A7ME43AFNAA
VFD2A7ME43ANSAA
VFD2A7ME43AFSAA
2.7 5.4 8.102 DR003A0810 DR003L0810 18.709 DR003D1870
VFD4A2ME43ANNAA
VFD4A2ME43AFNAA
VFD4A2ME43ANSAA
VFD4A2ME43AFSAA
4.2 8.4 6.077 DR004A0607 DR004L0607 14.031 DR004D1403
VFD5A5ME43ANNAA
VFD5A5ME43AFNAA
VFD5A5ME43ANSAA
VFD5A5ME43AFSAA
5.5 11 4.05 DR006A0405 DR006L0405 9.355 DR006D0935
VFD7A3ME43ANNAA
VFD7A3ME43AFNAA
VFD7A3ME43ANSAA
VFD7A3ME43AFSAA
8.1 16.2 2.7 DR009A0270 DR009L0270 6.236 DR009D0623
VFD9A0ME43ANNAA
VFD9A0ME43AFNAA
VFD9A0ME43ANSAA
VFD9A0ME43AFSAA
9 18 2.7 DR009A0270 DR009L0270 6.236 DR009D0623
VFD13AME43ANNAA
VFD13AME43AFNAA
VFD13AME43ANSAA
VFD13AME43AFSAA
13 26 1.174 DR018A0117 DR018L0117 4.677 DR012D0467
VFD17AME43ANNAA
VFD17AME43AFNAA
VFD17AME43ANSAA
VFD17AME43AFSAA
17 34 1.174 DR018A0117 DR018L0117 3.119 DR018D0311
