Delta VFD2A8MS21ANSAA User Manual

Chapter 9 SpecificationsMS300
178
9-1 115V Models
115V models one-phase (without built-in filter)
Frame
A
C
Model VFD_ _ _ _ _ _ _ _ AA
1A6MS11_ _ _
2A5MS11_ _ _
4A8MS11_ _ _
ANS
ENS
ANS
ENS
ANS
ENS
Applicable Motor Output (kW)
0.2
0.4
0.75
Applicable Motor Output (HP)
1/4
1/2
1
Output*
Heavy Duty
Rated Output Capacity (kVA)
0.6
1.0
1.8
Rated Output Current (A)
1.6
2.5
4.8
Carrier Frequency (kHz)
2–15 (Default: 4)
Normal
Duty
Rated Output Capacity (kVA)
0.7
1.0
2.1
Rated Output Current (A)
1.8
2.7
5.5
Carrier Frequency (kHz)
2–15 (Default: 4)
Input
Rated Input
Current (A)
Heavy Duty
6.0
9.4
18
Normal Duty
6.8
10.1
20.6
Rated Voltage / Frequency
One-phase 100–120 V
AC
(-15–10%), 50/60 Hz
Mains Input Voltage Range (V
AC
)
85–132
Mains Frequency Range (Hz)
47–63
Weight (kg)
0.65
0.74
1.24
Cooling Method
Convective cooling
Fan cooling
EMC Filter
Optional
IP Rating
IP20
IP40*
IP20
IP40*
IP20
IP40*
Table 9-1
NOTE:
1. Output*: Default is heavy duty.
2. IP40*: The IP ratings of the wiring area (main circuit terminals and control terminals for frame A/B/C/D/E/F)
and the vent near the capacitor (frame C/D/E/F) are both IP20.
3. The value of the carrier frequency is a factory default. Decrease the current value if you need to increase the
carrier frequency. Refer to Section 9-7 Derating for Ambient Temperature and Altitude for details.
4. For shock or impact load applications, select a drive with a larger capacity model.
