Delta VFD2A8MS21ANSAA User Manual

Chapter 11 Summary of Parameter SettingsMS300
253
11 Advanced Parameters
Pr.
Explanation
Settings
Default
11-00
System Control
bit 0: Auto-tuning for ASR and APR
bit 3: Dead time compensation closed
bit 7: Save or do not save the frequency
0
11-01
Per-Unit of System Inertia
1–65535 (256 = 1 PU)
256

11-02
ASR1／ASR2 Switch
Frequency
5.00–599.00 Hz
7.00

11-03
ASR1 Low-Speed
Bandwidth
1–40 Hz
Read only

11-04
ASR2 High-Speed
Bandwidth
1–40 Hz
Read only

11-05
Zero-Speed Bandwidth
1–40 Hz
Read only

11-06
ASR1 Gain
0–40 Hz
10

11-07
ASR1 Integral Time
0.000–10.000 sec.
0.100

11-08
ASR2 Gain
0–40 Hz
10

11-09
ASR2 Integral Time
0.000–10.000 sec.
0.100

11-10
ASR Gain of Zero Speed
0–40 Hz
10

11-11
ASR Integral Time of Zero
Speed
0.000–10.000 sec.
0.100

11-12
Gain for ASR Speed Feed
Forward
0–200%
0

11-13
PDFF Gain Value
0–200%
30

11-14
ASR Output Low Pass
Filter Time
0.000–0.350 sec.
0.008

11-15
Notch Filter Depth
0–20 dB
0

11-16
Notch Filter Frequency
0.00–200.00 Hz
0.00

11-17
Forward Motor Torque Limit
0–500%
500

11-18
Forward Regenerative
Torque Limit
0–500%
500

11-19
Reverse Motor Torque Limit
0–500%
500

11-20
Reverse Regenerative
Torque Limit
0–500%
500

11-21
Flux Weakening Curve for
Motor 1 Gain Value
0–200%
90

11-22
Flux Weakening Curve for
Motor 2 Gain Value
0–200%
90

11-23
Flux Weakening Area
Speed Response
0–150%
65
