Delta VFD2A8MS21ANSAA User Manual

Chapter 9 SpecificationsMS300
183
9-3 460V Models
460V models three-phase
Frame
A
B
Model VFD_ _ _ _ _ _ _ _AA
1A5MS43_ _ _
2A7MS43_ _ _
1A5MS43AFS
2A7MS43AFS
4A2MS43_ _ S
ANS
ENS
ANS
ENS
AN
EN
AF
Applicable Motor Output (kW)
0.4
0.75
0.4
0.75
1.5
Applicable Motor Output (HP)
0.5
1
0.5
1
2
Outpu
t*
Heavy Duty
Rated Output Capacity (kVA)
1.1
2.1
1.1
2.1
3.2
Rated Output Current (A)
1.5
2.7
1.5
2.7
4.2
Carrier Frequency (kHz)
2–15 (Default: 4)
Normal Duty
Rated Output Capacity (kVA)
1.4
2.3
1.4
2.3
3.5
Rated Output Current (A)
1.8
3
1.8
3
4.6
Carrier Frequency (kHz)
2–15 (Default: 4)
Input
Rated Input
Current (A)
Heavy Duty
1.7
3.0
1.7
3.0
4.6
Normal Duty
2.0
3.3
2.0
3.3
5.1
Rated Voltage / Frequency
Three-phase 380–480 V
AC
( -15–10%), 50／60 Hz
Mains Input Voltage Range (V
AC
)
323–528
Mains Frequency Range (Hz)
47–63
Weight (kg)
0.76
0.81
1.32
1.32
1.0
1.32
Cooling Method
Convective cooling
Fan cooling
EMC Filter
Optional
Built-in
Optional
Built-
in
IP Rating
IP20
IP40*
IP20
IP40*
IP20
IP40*
IP20
Table 9-6
NOTE:
1. Output*: Default is heavy duty.
2. IP40*: The IP ratings of the wiring area (main circuit terminals and control terminals for frame A/B/C/D/E/F)
and the vent near the capacitor (frame C/D/E/F) are both IP20.
3. The value of the carrier frequency is a factory default. Decrease the current value if you need to increase the
carrier frequency. Refer to Section 9-7 Derating for Ambient Temperature and Altitude for details.
4. For shock or impact load applications, select a drive with a larger capacity model.
