Chapter 12 Description of Parameter SettingsME300
12.1-02-11
29: Output when frequency ≥ Pr.02-34
30: Output when frequency
< Pr.02-34
31: Y-connection for the motor coil
32: ∆-connection for the motor coil
33: Zero speed (actual output frequency)
34: Zero speed include STOP (actual output frequency)
35: Error output selection 1 (Pr.06-23)
36: Error output selection 2 (Pr.06-24)
37: Error output selection 3 (Pr.06-25)
38: Error output selection 4 (Pr.06-26)
40: Speed reached (including STOP)
42: Crane function
43: Motor speed slower than Pr.02-47
44: Low current output (use with Pr.06-71–Pr.06-73)
45: UVW output electromagnetic valve ON / OFF switch
46: Master dEb output
51:
Output control for RS-485
66: SO output logic A (use with STO card)
67: Analog input level reached
68: SO output logic B (use with STO card)
69: Indication of Preheating
75: Forward RUN status
76: Reverse RUN status
77: Program Running Indication
78: Program Step Completed Indication
79: Program Running Completed Indication
80: Program Running Paused Indication
81: Multi-pump system error display (only master)
Use this parameter to set the function of the multi-function terminals.
Summary of function settings
Take the normally open contact (N.O.) for example, ON: contact is closed, OFF: contact is open.
Settings Functions Descriptions
0 No Function Output terminal with no function
1 Indication during RUN Active when the drive is not in STOP.
2
Operation speed
reached
Active when output frequency of the drive reaches the setting
frequency.
3
Desired frequency
reached 1 (Pr.02-22)
Active when the desired frequency (Pr.02-22) reached.
4
Desired frequency
reached 2 (Pr.02-24)
Active when the desired frequency (Pr.02-24) reached.
