Denon AVR-1604 Service Manual

38
38
AVR-1604/684 / AVC-1580
CNT P.W.B. UNIT
Ref. No. Part No. Part Name Remarks New
SEMICONDUCTORS GROUP
IC401 963 0043 700 IC LC72131 E3,EU,E2,EK,E2A,E1C,EUT,E1K
IC402 963 0043 904 IC LA1266 E3,EU,E2,EK,E2A,E1C,EUT,E1K
IC403 963 0044 000 IC LA3401 E3,EU,E2,EK,E2A,E1C,EUT,E1K
IC621,622 960 0180 101 IC LA7952
IC651 960 0175 200 IC BA7625 E3,EU
IC652,653 963 0083 304 IC BA7626 E3,EU
IC701 960 0174 104 IC CXA1511M E3,EU
Q101SB 963 0044 204 Transistor 2SD2390-Y
Q102SB 963 0044 107 Transistor 2SB1560-Y
Q103SB 963 0058 106 Transistor 2SD947F
Q104SB 960 0196 506 Transistor KSC1845F
Q401 960 0189 102 Transistor KTC3880S-O E3,EU,E2,EK,E2A,E1C,EUT,E1K
Q402 963 0121 703 Transistor KRA107S E3,EU,E2,EK,E2A,E1C,EUT,E1K
Q403,404 963 0120 704 Transistor KRA102S E3,EU,E2,EK,E2A,E1C,EUT,E1K
Q405,406 960 0196 603 Transistor KTC2874B E3,EU,E2,EK,E2A,E1C,EUT,E1K
Q407 963 0121 606 Transistor KRC107S E3,EU,E2,EK,E2A,E1C,EUT,E1K
Q408 963 0120 704 Transistor KRA102S E3,EU,E2,EK,E2A,E1C,EUT,E1K
Q409 960 0189 102 Transistor KTC3880S-O E2,EK,E2A
Q501SB 960 0196 603 Transistor KTC2874B
Q502SB,503SB 960 0196 205 Transistor KSA992F
Q504SB 960 0196 506 Transistor KSC1845F
Q551 960 0196 700 Transistor KTC3200BL
Q552 960 0196 302 Transistor KTA1268BL
Q553-556 960 0097 207 Transistor KRA102M
Q621,622 960 0005 202 Transistor KTC3198Y
Q623,624 963 0121 208 Transistor KRC107M
Q625,626 960 0005 202 Transistor KTC3198Y
Q627,628 963 0121 208 Transistor KRC107M
Q651-653 960 0005 105 Transistor KTA1266Y E3,EU
Q701 960 0097 003 Transistor KRA104M E3,EU
D102SB 963 0020 309 Diode 1SS133T
D403 963 0096 605 Diode 1N4148WS E3,EU,E2,EK,E2A,E1C,EUT,E1K
D404 963 0020 309 Diode 1SS133T E3,EU,E2,EK,E2A,E1C,EUT,E1K
D405,406 963 0096 605 Diode 1N4148WS E3,EU,E2,EK,E2A,E1C,EUT,E1K
D551 963 0020 309 Diode 1SS133T
D552-561 963 0020 309 Diode 1SS133T
D562,563 963 0058 407 Diode IN4007
D564 960 0095 500 Zener diode MTZJ5.1B
D565-567 963 0020 309 Diode 1SS133T
D621,622 963 0020 309 Diode 1SS133T
D701 960 0095 704 Zener diode MTZJ6.2B E3,EU
ZD401 960 0095 500 Zener diode MTZJ5.1B E3,EU,E2,EK,E2A,E1C,EUT,E1K
RESISTORS GROUP
J401-404 963 9003 369 Carbon chip 0 ohm 1/8W E3,EU,E2,EK,E2A,E1C,EUT,E1K
J407 963 9003 369 Carbon chip 0 ohm 1/8W E3,EU,E2,EK,E2A,E1C,EUT,E1K
J409 963 9003 369 Carbon chip 0 ohm 1/8W E3,EU,E2,EK,E2A,E1C,EUT,E1K
R104SB,105SB 963 9006 285 Metal oxide 5.6 kohm 1W
R106SB,107SB 963 0047 900 Metal film 4.7 kohm 1W
R108SB-111SB 963 9006 269 Metal oxide 0.22 ohm 1W

Denon AVR-1604 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Audio output channels	6.1 channels
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Ethernet LAN	No
Supported radio bands	AM, FM
Product color	Black
Audio decoders	DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
