Denon AVR-1604 Service Manual

59
59
AVR-1604/684 / AVC-1580
72 963 0094 005 INPUT CUSHION E2,EK,E2A,E1C,EUT,E1K 1
74 963 0101 600 PCB BRACKET E2,EK,E2A,E1C,EUT,E1K 4
★
960 0093 104 PUSH LIVET E2,EK,E2A,E1C,EUT,E1K 12
★
963 0068 400 CAPACITOR COVER E2,EK,E2A,E1C,E1K,N 1
★
960 0155 301 CLAMP 5
★
963 0120 403 FUSE CAUTION LABEL E3,EU,EUT 1
★
963 0120 500 FUSE LABEL E2,EK,E2A,E1C,E1K 1
★
963 0120 513 FUSE LABEL N 1
★
963 0120 526 FUSE LABEL N 1
★
963 0098 001 FFC CABLE 1
★
- SERIAL LABEL E3,EU,E2,EK,E2A 1
N2
★
- SERIAL LABEL E1K 1
SCREWS
A 963 0018 007 SCREW (2S 3X8 ZNY/BH) 47
B 960 9008 527 SCREW (2S 3X8 WASHER) Black model,E1C 4
C 963 0048 200 SCREW (2S 3X10 ZNY/BH) 5
D 960 0108 714 SCREW (2S 3X10 DOT BK) 41
E 963 9006 175 SCREW (2S 3X14 WASHER ZNY/HH) 18
F 963 0018 104 SCREW (2S 3X17 ZNY/BH) 4
G 963 0048 307 SCREW (2S 4X8 DOT BK) Black model 6
963 9004 012 SCREW (2S 4X8 DOT NI) Silver & Gold models 6
H 960 9008 417 SCREW (3S 4X8 ZNY/BH) 4
J 963 9004 025 SCREW (3S 4X6 ZNY/BH) 6
K 963 9004 038 SCREW (2S 3X8 ZNY) 2
L 960 9008 420 SCREW (2S 3X8 WASHER) Black model 3
Silver & Gold models 7
M 963 9004 041 SCREW (2S 3X5 ZNY/BH) E2,EK,E2A,E1C,EUT,E1K 4
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1604 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Audio output channels	6.1 channels
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Ethernet LAN	No
Supported radio bands	AM, FM
Product color	Black
Audio decoders	DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
