Denon AVR-1604 Service Manual

62
62
AVR-1604/684 / AVC-1580
WIRING DIAGRAM
H/P & S/W B'D
TRANS
3P 250mm WIRE
11PIN 14PIN
FUNCTION B'D
3P 80mm WIRE
5P 80mm WIRE
AC CORD
5PIN
S-VIDEO B'DCOM-VIDEO B'D
S-VIDEO CNT B'D
3PIN
8PIN
5PIN 9PIN
MAIN AMP B'D
PRE AMP B'D
6PIN10PIN
16P 80mm WIRE
12PIN
19PIN 16PIN
CPU B'D
SB-AMP B'D
12PIN
HEAT SINK
VIDEO B'D
3PIN
14P 160mm WIRE
8PIN
VIDEO CNT B'D
13PIN
8PIN
5PIN
DSP B'D
15PIN 19PIN
10PIN
INPUT B'D
10PIN 17PIN
TUNER_EXT_IN (1604)
TUNER_EX_IN (1580)
FRONT B'D
CONNECTION B'D
10PIN
4P 80mm WIRE
15PIN
20P 160mm CARD CABLE
6P 200mm SHIELD WIRE

Denon AVR-1604 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Audio output channels	6.1 channels
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Ethernet LAN	No
Supported radio bands	AM, FM
Product color	Black
Audio decoders	DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
