Denon AVR-1604 Service Manual

47
47
AVR-1604/684 / AVC-1580
DSP P.W.B. UNIT
Ref. No. Part No. Part Name Remarks New
SEMICONDUCTORS GROUP
IC801,802 963 0113 106 IC GP1FA513RZ
IC804 963 0096 304 IC DSP MELODY 32 LQFP
IC805 963 0114 406 IC M29W800AT
IC806 963 0095 606 IC IS61LV6416-12T
IC807 963 0096 100 IC LC89057W
IC808 963 0096 207 IC AD1837
IC809-811 963 0074 203 IC MM74LCX244WMX
IC812 963 0074 300 IC MM74HCT244WMX
IC813 963 0095 907 IC 74LCX02MTC
IC814 963 0102 308 IC MM74HC00MTCX
IC815A,816A 963 0043 807 IC BA4510F
IC817 963 0113 009 IC GP1FA513TZ
IC817A-820A 963 0024 004 IC NJM2068M
IC821 963 0096 003 IC 74LCX74MTC
IC822 960 0159 501 IC KIA7805API
IC823 963 0111 603 IC RC1117-3.3
IC824 963 0111 506 IC RC1117-2.5
Q804C,FL,FR,SB,SL,SR,SW 960 0196 603 Transistor KTC2874B
Q805 963 0120 704 Transistor KRA102S
Q806 963 0120 801 Transistor KRC102S
Q807 963 0120 704 Transistor KRA102S
D801 963 0096 605 Diode 1N4148WS
D806,807 963 0096 605 Diode 1N4148WS
RESISTORS GROUP
R1005 963 0120 908 Bead
R1033-1035 963 0120 908 Bead
CAPACITORS GROUP
C01-05 963 9004 708 Ceramic chip 0.1uF/50V
C801 963 9004 708 Ceramic chip 0.1uF/50V
C802-805 963 9004 591 Ceramic chip 22pF/50V
C807 963 9004 708 Ceramic chip 0.1uF/50V
C810 963 9004 708 Ceramic chip 0.1uF/50V
C811 963 9006 421 Electrolytic 47uF/10V
C812 963 9004 708 Ceramic chip 0.1uF/50V
C813 963 9006 421 Electrolytic 47uF/10V
C814 963 9004 591 Ceramic chip 22pF/50V
C817 963 9006 366 Electrolytic 0.1uF/50V
C818 963 9004 698 Ceramic chip 0.01uF/50V
C820 963 9006 421 Electrolytic 47uF/10V
C821 963 9006 324 Electrolytic 100uF/10V
C822 963 9004 708 Ceramic chip 0.1uF/50V
C823 963 9006 298 Electrolytic 10uF/35V
C825 963 9006 379 Electrolytic 1uF/50V
C826 963 9006 298 Electrolytic 10uF/35V
C835 963 9005 901 Electrolytic 470uF/10V
C838,839 963 9004 708 Ceramic chip 0.1uF/50V
C840 963 9004 698 Ceramic chip 0.01uF/50V

Denon AVR-1604 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Audio output channels	6.1 channels
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Ethernet LAN	No
Supported radio bands	AM, FM
Product color	Black
Audio decoders	DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
