Denon AVR-1604 Service Manual

43
43
AVR-1604/684 / AVC-1580
PRE-AMP P.W.B. UNIT
Ref. No. Part No. Part Name Remarks New
SEMICONDUCTORS GROUP
Q501C,FL,FR,SL,SR 960 0196 603 Transistor KTC2874B
Q502C,FL,FR,SL,SR 960 0196 205 Transistor KSA992F
Q503C,FL,FR,SL,SR 960 0196 205 Transistor KSA992F
Q504C,FL,FR,SL,SR 960 0196 506 Transistor KSC1845F
ZD341,342 960 0095 500 Zener diode MTZJ5.1B
RESISTORS GROUP
R509C,FL,FR,SL,SR 960 9005 902 Metal film 1.2 kohm 1/4W
R511C,FL,FR,SL,SR 960 9004 301 Metal film 47 ohm 1/4W
R901,902 960 9009 270 Metal film 470ohm 2W
CAPACITORS GROUP
C341,342 963 9004 546 Ceramic 0.01uF/16V
C501C,FL,FR,SL,SR 963 9006 382 Electrolytic 22uF/25V
C501M 963 9006 308 Electrolytic 10uF/50V
C502C,FL,FR,SL,SR 963 9006 308 Electrolytic 10uF/50V
C503C,FL,FR,SL,SR 963 9003 165 Ceramic 220pF/500V
C504C,FL,FR,SL,SR 963 9003 178 Ceramic 220pF/50V
C505C,FL,FR,SL,SR 963 9003 181 Ceramic 33pF/500V
C506C,FL,FR,SL,SR 963 9006 324 Electrolytic 100uF/10V
C507C,FL,FR,SL,SR 963 9003 194 Mylar film 0.0022uF/100V
C901,902 963 9004 533 Ceramic 0.001uF/50V
C903 963 9006 379 Electrolytic 1uF/50V
C904 960 9003 108 Ceramic 0.022uF/25V E3,EU,N
C905 960 9003 108 Ceramic 0.022uF/25V
OTHER PARTS GROUP
CN392 963 0087 300 3P connector cord
CN501 963 0085 506 9P connector socket (TUC-P)
CN502 963 0086 505 7P connector socket (TUC-P)
CN503,504 963 0085 603 5P connector socket (TUC-P)
CN505 963 0085 409 10P connector socket (TUC-P)
CN557 963 0115 308 13P connector base
CN901 963 0090 902 3P WIRE
CP302 963 0075 600 6P connector base
CP392 963 0048 909 3P connector base
CP554A 963 0097 701 12P connector base
CP554B 963 0050 104 4P connector base
G901 - 1P contact Ass'y E3,EU,N
JK901 963 0095 402 Head phone jack
! SW901 960 0176 209 Push switch E3,EU,N
VEC303 963 0095 208 ENCODER SW
