Denon AVR-1802 Service Manual

28
AVR-1802/882
PARTS LIST OF P.W.B. UNIT
MAIN P.W.B. ASS'Y
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
Note: The symbols in the column “Remarks” indicate the following destinations.
E3: U.S.A. model, Canada model E1C: China model
EU: U.S.A. model (AVR-882) E1H: Hong Kong model
E2: Europe model E1T: Taiwan R.O.C. model
E1: Asia model
R106FL,FR 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R106SL,SR 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R107C 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R107FL,FR 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R107SL,SR 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R108C 244 2043 982 Metal oxide 0.22ohm 1W
R108FL,FR 244 2043 982 Metal oxide 0.22ohm 1W
R108SL,SR 244 2043 982 Metal oxide 0.22ohm 1W
R109C 244 2043 982 Metal oxide 0.22ohm 1W
R109FL,FR 244 2043 982 Metal oxide 0.22ohm 1W
R109SL,SR 244 2043 982 Metal oxide 0.22ohm 1W
R110C 244 2043 982 Metal oxide 0.22ohm 1W
R110FL,FR 244 2043 982 Metal oxide 0.22ohm 1W
R110SL,SR 244 2043 982 Metal oxide 0.22ohm 1W
R111C 244 2043 982 Metal oxide 0.22ohm 1W
R111FL,FR 244 2043 982 Metal oxide 0.22ohm 1W
R111SL,SR 244 2043 982 Metal oxide 0.22ohm 1W
R118C 244 2043 937 Metal oxide 10 ohm 1W
R118FL,FR 244 2043 937 Metal oxide 10 ohm 1W
R118SL,SR 244 2043 937 Metal oxide 10 ohm 1W
R119C 244 2043 937 Metal oxide 10 ohm 1W
R119FL,FR 244 2043 937 Metal oxide 10 ohm 1W
R119SL,SR 244 2043 937 Metal oxide 10 ohm 1W
R135,136 963 0045 203 Winding 0.1 ohm 5W
R141,142 244 2043 982 Metal oxide 0.22 ohm 1W
R148,149 244 2043 982 Metal oxide 0.22 ohm 1W
R151 963 9003 343 Metal film 68ohm 1/4W
R154 963 0043 108 Metal film 2.2 Mohm 1/2W
R179 963 9003 055 Metal film 47 kohm 1/4W (NB)
R181 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R184 244 2043 937 Metal oxide 10 ohm 1W
R185 963 9003 039 Metal film 1 ohm 1/4W
R700L,R 963 9003 372 Carbon chip 0 ohm 1/16W
R701L,R 963 9004 290 Carbon chip 390 ohm 1/16W
R702L,R 963 9004 339 Carbon chip 470 ohm 1/16W
R703L,R 963 9004 339 Carbon chip 470 ohm 1/16W
R704L,R 963 9004 339 Carbon chip 470 ohm 1/16W
R705L,R 963 9004 339 Carbon chip 470 ohm 1/16W
R706L,R 963 9004 339 Carbon chip 470 ohm 1/16W
R707L,R 963 9004 339 Carbon chip 470 ohm 1/16W
R708L,R 963 9004 339 Carbon chip 470 ohm 1/16W
R709L,R 963 9004 452 Carbon chip 68 kohm 1/16W
R710L,R 963 9004 245 Carbon chip 2.2 Mohm 1/16W
R711L,R 963 9004 245 Carbon chip 2.2 Mohm 1/16W
R712L,R 963 9004 245 Carbon chip 2.2 Mohm 1/16W
R713L,R 963 9004 245 Carbon chip 2.2 Mohm 1/16W
R714L,R 963 9004 245 Carbon chip 2.2 Mohm 1/16W
R715L,R 963 9004 245 Carbon chip 2.2 Mohm 1/16W
R716L,R 963 9004 245 Carbon chip 2.2 Mohm 1/16W
R717L,R 963 9004 164 Carbon chip 150 kohm 1/16W
R718L,R 963 9004 326 Carbon chip 47 ohm 1/10W
SEMICONDUCTORS GROUP
IC101 963 0057 903 IC KIA7815AP
IC102 963 0044 806 IC NJM7915FA
IC103 960 0196 001 IC NJM7805FA (S)
IC104 963 0057 709 IC KIA7805AP
IC105 960 0195 808 IC protector ICP-N15
IC701 963 0083 207 IC TC9274N-011
IC702~704 960 0174 502 IC NJM2068DD
Q104C 960 0196 506 Transistor KSC1845F
Q104FL,FR 960 0196 506 Transistor KSC1845F
Q104SL,SR 960 0196 506 Transistor KSC1845F
Q111~115 960 0196 904 Transistor DTC114YS (NPN)
Q116 960 0196 409 Transistor 2SC1740SR
Q117 960 0196 904 Transistor DTC114YS (NPN)
Q151 960 0196 409 Transistor 2SC1740SR
Q171~177 960 0005 202 Transistor KTC3198 (Y)
Q171A~C 960 0196 302 Transistor KTA1268BL
Q178 960 0005 105 Transistor KTA1266Y
Q179 960 0189 005 Transistor KSA916Y
Q180,181 960 0196 302 Transistor KTA1268BL
D101~105 963 0020 309 Diode 1SS133T
D121~126 963 0020 309 Diode 1SS133T
D131A,B 960 0197 107 Diode KBPC604
D132 963 0020 309 Diode 1SS133T
D133,134 963 0046 202 Zener diode MTZJ18B
D135 963 0020 309 Diode 1SS133T
D136 963 0058 504 Zener diode MTZJ11B
D137 963 0020 309 Diode 1SS133T
D138 963 0058 407 Diode IN4007
D141~146 963 0058 407 Diode IN4007
D148 963 0020 309 Diode 1SS133T
D149,150 963 0058 407 Diode IN4007
D151 963 0020 309 Diode 1SS133T
D152,153 963 0058 407 Diode IN4007
D154 963 0047 405 Zener diode MTZJ7.5B
D157 960 0014 905 Zener diode MTZJ20B
D158~160 963 0020 309 Diode 1SS133T
D251~256 960 0197 000 Diode KDS160
RESISTORS GROUP
R104C 244 2052 957 Metal oxide 5.6kohm 1W
R104FL,FR 244 2052 957 Metal oxide 5.6kohm 1W
R104SL,SR 244 2052 957 Metal oxide 5.6kohm 1W
R105C 244 2052 957 Metal oxide 5.6kohm 1W
R105FL,FR 244 2052 957 Metal oxide 5.6kohm 1W
R105SL,SR 244 2052 957 Metal oxide 5.6kohm 1W
R106C 963 9003 068 Metal film 4.7 ohm 1/4W (NB)

Denon AVR-1802 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	115 W
Power output per channel (20-20KHz@8 Ohm)	80 W
AC input voltage	120 V
AC input frequency	60 Hz
Equalizer	Yes
Audio decoders	DTS, Dolby Digital, Dolby Pro Logic II
3D	No
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
HDMI in	0
Composite video in	5
S-Video inputs quantity	4
Digital audio coaxial in	1
Digital audio optical in	3

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	171 mm
Weight	10900 g
