Denon AVR-1802 Service Manual

42
AVR-1802/882
PARTS LIST OF EXPLODED VIEW
Ref. No. Part No. Part Name Remarks Q'ty Ref. No. Part No. Part Name Remarks Q'ty
Note: The symbols in the column “Remarks” indicate the following destinations.
E3: U.S.A. model, Canada model E1C: China model
EU: U.S.A. model (AVR-882) E1H: Hong Kong model
E2: Europe model E1T: Taiwan R.O.C. model
E1: Asia model
963 0082 606 Main P.W.B assy for E3, EU 1
963 0082 622 for E2 1
963 0082 635 for E1C 1
963 0082 648 for E1, E1H, E1T 1
43 Main P.W.B assy 1
44 Front-CNT P.W.B assy 1
51 Input P.W.B assy 1
963 0082 703 Processor P.W.B assy for E3, EU 1
963 0082 729 for E2 1
963 0082 732 for E1C
963 0082 745 for E1, E1H, E1T 1
12 Front P.W.B assy 1
50 CPU P.W.B assy 1
62 Front-Optical P.W.B assy 1
963 0082 907 CNT P.W.B assy for E3, EU 1
963 0082 923 for E2
963 0082 936 for E1C
963 0082 949 for E1, E1H, E1T 1
10 Head phone P.W.B assy 1
11 Switch P.W.B assy 1
26 Video-CNT P.W.B assy 1
35 CNT P.W.B assy 1
45 Preout P.W.B assy 1
46 S-Video P.W.B assy 1
47 CDR-CNT P.W.B assy 1
48 Video P.W.B assy 1
53 Tuner P.W.B assy 1
65 Outlet P.W.B assy 1
963 0082 800 Pre-Amp P.W.B assy for E3, EU 1
963 0082 826 for E2
963 0082 839 for E1C
963 0082 842 for E1, E1H, E1T
56 Pre-Amp P.W.B assy 1
963 0083 003 DSP P.W.B assy for E3, EU 1
963 0083 029 for E2
963 0083 032 for E1C
963 0083 045 for E1, E1H, E1T
49 DSP P.W.B assy 1
963 0088 600 Voltage P.W.B assy for E1,E1H,E1T 1
63 Voltage P.W.B assy for E1,E1H,E1T 1
1 963 0082 004 Front panel for E3 1
963 0082 062 for EU
963 0082 017 for E2 (Black model) 1
963 0082 020 for E2 (Gold model) 1
963 0082 046 for E1 (Gold model) 1
963 0082 059 for E1 (Black model) 1
2 960 0185 009 Power button for Black model 1
963 0055 206 Power button (GO) for Gold model 1
3 963 0082 305 Window 1
4 963 0054 906 Main volume knob for Black model 1
963 0055 002 Main volume knob (GO):MOLD for E2 (Gold model) 1
112 0839 008 Main volume knob (GO) : AL for E1, E1C, E1H, E1T 1
5 963 0054 809 Select knob(BK) for E3, EU, E2/Black model 1
963 0055 109 Select knob (GO) : MOLD for E2 (Gold model) 1
112 0835 015 Select knob (GO) : AL for E1, E1C, E1H, E1T 1
6 963 0051 307 Lens 2
7 963 0082 208 Front frame for Black model 1
963 0082 211 for Gold model 1
8 960 0176 209 Push switch for E3, EU 1
963 0056 603 Push switch for E1, E1C, E1H, E1T, E2 1
9 960 0187 502 Head phone jack (D6.5) for E3, EU, E2 1
960 0176 306 Head phone jack (D6.5) for E1, E1C, E1H, E1T 1
13 960 0180 509 FLT (16-ST-42GNK) 1
14 960 0181 100 IC NJL64H380A RMC301 1
15 960 0197 204 LED PI5-RD/HL50RDRF4T LED301-309 8
16 960 0184 408 FLT holder 1
17 960 0184 301 Heat sink bracket F 1
18 960 0181 207 Rotary encoder (L=25) VEC301 1
960 0181 207 Rotary encoder (L=25) VEC302 1
963 0084 109 Rotary encoder (L=20) VEC302 (for E1, E1C, E1H, E1T) 1
19 963 0044 107 Transistor 2SB1560Y Q102C,FL,FR,SL,SR 5
20 960 0187 900 Posistor P43T7D330BW16 1
21 963 0058 106 Transistor 2SD947F Q103C,FL,FR,SL,SR 5
22 963 0044 204 Transistor 2SD2390Y Q101C,FL,FR,SL,SR 5
23  Heat sink 1
24 960 0184 204 Heat sink bracket B 1
25 960 0183 205 Top cabinet for Black model 1
963 0055 507 Top cabinet for Gold model 1
27  Wire clamp 2
28 960 0198 216 Chassis 1
29 960 0183 904 Foot assy 4
30 963 0051 103 Card spacer 2
31 960 0003 301 PCB supporter 2
32 960 0184 107 Supporter bracket 1
33 960 0192 306 Trans bracket 1
34 960 0184 000 Screw bracket 4
36 963 0088 503 Power trans for E3, EU 1
963 0088 516 for E2 1
963 0088 529 for E1, E1H, E1T 1
963 0088 532 for E1C 1
37  Heat sink 1
38  Heat sink 1
39 960 0187 803 AC outlet(2P) JK104 For E3,EU 1
39 960 0143 203 AC outlet for E2,E1,E1H,E1T 1
40 960 0194 809 2P speaker terminal JK103 1
41 963 0074 009 8P speaker terminal 1
42 960 0188 608 4P speaker terminal 1
52 963 0088 406 Plate 1
54 963 0054 003 Shield tuner pack 1

Denon AVR-1802 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	115 W
Power output per channel (20-20KHz@8 Ohm)	80 W
AC input voltage	120 V
AC input frequency	60 Hz
Equalizer	Yes
Audio decoders	DTS, Dolby Digital, Dolby Pro Logic II
3D	No
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
HDMI in	0
Composite video in	5
S-Video inputs quantity	4
Digital audio coaxial in	1
Digital audio optical in	3

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	171 mm
Weight	10900 g
