Denon AVR-1802 Service Manual

for E1,E1H,E1T
for E3,EU
for E2,E1,E1H,E1T
8
76
5
4
3
2
1
A
B
C
D
E
EXPLODED VIEW
AVR-1802/882
41
WARNING:
Parts marked with this symbol have critical
characteristics.
Use ONLY r eplacement parts recommended by the
manufacturer.
Note: The symbols indicate the following
destinations.
E3 : U.S.A. model, Canada model
EU : U.S.A. model (AVR-882)
E2 : Europe model
E1 : Asia model
E1C : China model
E1H : Hong kong model
E1T : Taiwan R.O.C. model

Denon AVR-1802 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	115 W
Power output per channel (20-20KHz@8 Ohm)	80 W
AC input voltage	120 V
AC input frequency	60 Hz
Equalizer	Yes
Audio decoders	DTS, Dolby Digital, Dolby Pro Logic II
3D	No
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
HDMI in	0
Composite video in	5
S-Video inputs quantity	4
Digital audio coaxial in	1
Digital audio optical in	3

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	171 mm
Weight	10900 g
