Denon AVR-988 Service Manual

11
AVR-2808CI / AVR-988
2. Analog video
2.1. MONITOR OUT (CVBS) Output NG
MONITOR OUT (CVBS) Output NG
※ When checking operation, select
DVD for the function.
(COMPONENT1 input)
Checking the video convert ON/OFF settings
Video convert ON
Video convert OFF
Input
CVBS
Input
S
Input
COMPONENT
Input
CVBS
Input
S
I n p u t
COMPONENT
AB
Interlace
o r
Progressive
D No output No output
Interlace
C
Progressive
no output
2. アナログビデオ
2.1. MONITOROUT(CVBS)出力NG
MONITOROUT(CVBS)出力NG ※ 動作を確認する時はファンクショ
ンを DVD に選択してください。
(COMPONENT1入力 )
ﾋﾞﾃﾞｵｺﾝﾊﾞｰﾄON/OFFの設定確認
ﾋﾞﾃﾞｵｺﾝﾊﾞｰﾄON ﾋﾞﾃﾞｵｺﾝﾊﾞｰﾄOFF
入力
CVBS
入力
S
入力
COMPONENT
入力
CVBS
入力
S
入力
COMPONENT
Aへ Bへ ｲﾝﾀｰﾚｰｽ
or
ﾌﾟﾛｸﾞﾚｯｼﾌﾞ
D へ 出力されません 出力されません
ｲﾝﾀｰﾚｰｽ
Cへ
ﾌﾟﾛｸﾞﾚｯｼﾌﾞ
出力されません
