AVR-2808CI / AVR-988
PARTS LIST OF EXPLODED VIEW
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に"nsp" と記載されている基板 ASS'Y は供給できません。基板 ASS'Y の修理の際には基板部品表を確認のうえ、交換部品を発注してください。
＊ P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement
parts.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
2808CIEU : U.S.A. model 2808CIEC : Canada model 988EU : U.S.A. model
Ref. No. Part No. Part Name Remarks Q'ty New
1 00D 1U- 3838 DIGITAL UNIT ASSY 1U-3838 :DIGITAL UNIT : 2808CI 1 *
1 00D 1U- 3838 E DIGITAL UNIT ASSY 1U-3838E :DIGITAL UNIT : 988EU 1 *
2 nsp A.AUDIO/VIDEO UNIT ASSY 1U-3839 : 2808CI *
2 nsp A.AUDIO/VIDEO UNIT ASSY 1U-3839E : 988EU *
2-1 A.VIDEO UNIT 1
2-2 AUDIO UNIT 1
2-3 ZONE UNIT 1
3 nsp FRONT UNIT ASSY 1U-3840 : 2808CI *
3-1 FLD UNIT 1
3-2 FUNC UNIT 1
3-3 FRONT IN UNIT 1
3-4 MIC UNIT 1
3-5 REMOTE/IPOD UNIT 1
3-6 DIGITAL I/O UNIT 1
3-7 V/D JOINT UNIT 1
3-8 UCON CONNECT UNIT 1
3-9 P.SW UNIT 1
3-11 FFC LOCK UNIT 1
4 nsp POWER REG. UNIT ASSY 1U-3841 : 2808CI *
4 nsp POWER REG. UNIT ASSY 1U-3841E : 988EU *
4-1 REG UNIT 1
4-6 PRE AMP UNIT
4-7 AUDIO CONNECT UNIT 1
4-8 AUDIO LIMIT UNIT 1
4-9 LIMIT CONNECT UNIT 1
4-10 V-POWER JUNCTION UNIT 1
5 nsp POWER AMP UNIT ASSY 1U-3854 *
5-1 P.AMP UNIT 1
5-10 REG CONNECT UNIT 1
5-11 P.AMP HOLDER UNIT 1
6 nsp MAIN CPU UNIT ASSY 1U-3857 : 2808CI *
6 nsp MAIN CPU UNIT ASSY 1U-3857E : 988EU *
6-1 MAIN CPU UNIT 1
6-2 POWER UNIT 1
6-3 PRIM/CPU SUPPLY UNIT 1
6-4 UCON JUNCTION UNIT 1
7 nsp FRONT UNIT ASSY 1U-3842 : 988EU *
7-1 FLD UNIT 1
7-2 KEY UNIT A 1
7-3 KEY UNIT B 1
