Denon AVR-S510BT Service Manual

Jump to the target of a schematic
diagram connector
Click the Ref. No. of the target connector in the red
box around a schematic diagram connector.
•The screen jumps to the target connector.
•Pagemagnicationstaysthesameasbeforethe
jump.
CP401
CP106
v
ABOUT THIS MANUAL
Readthefollowinginformationbeforeusingtheservicemanual.
What you can do with this manual
Search for a Ref. No. (phrase)
(Ctrl+Shift+F)
YoucanusethesearchfunctioninAcrobatReaderto
searchforaRef.No.inschematicdiagrams,printed
wiringcircuitdiagrams,blockdiagrams,andparts
lists.
1.PressCtrl+Shift+Fonthekeyboard.
• TheSearchwindowappears.
2.EntertheRef.No.youwanttosearchforinthe
Searchwindow,andthenclicktheSearchbutton.
•Alistofsearchresultsappears.
3.Clickanitemonthelist.
•Thescreenjumpstothepageforthatitem,andthe
searchphraseisdisplayed.
Ctrl
Shift
F
3

Denon AVR-S510BT Specifications

General

Channels	5.2
Power Output	70 Watts per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Response Bandwidth	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
HDMI Inputs	5
HDMI Outputs	1
HDMI Pass-Through	Yes
HDMI Version	2.0
HDCP Version	2.2
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Audio Decoding	Dolby TrueHD, DTS-HD Master Audio
Wi-Fi	No
Inputs	5 HDMI, 2 digital optical, 2 analog
Outputs	1 HDMI
Dimensions	17.1 in x 12.6 in x 5.9 in
Amplifier Output Details	5 channels
