Denon AVR-X2300W Service Manual

Proceeding ： TOP COVER → COVER → HDMI PCB → VIDEO PCB
(1) Remove the connectors.
5. VIDEO PCB
CN5003
CN5000
Proceeding ： TOP COVER → COVER → HDMI PCB → VIDEO PCB → MAIN PCB
(1) Remove the screws.
(2) Remove the screws. Remove the connectors.
Proceeding ： TOP COVER → SMPS PCB
See "EXPLODED VIEW" for instructions on removing the SMPS PCB.
Proceeding ： TOP COVER → COVER → HDMI PCB → TRANS
See "EXPLODED VIEW" for instructions on removing the transformer (TRANS).
6. MAIN PCB
View from the bottom
x3
x8
x2
from CP405
from CP403
CP402
CP401
CP401
CP5003
7. SMPS PCB
8. TRANS
65
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-X2300W Specifications

General

Receiver type	-
Audio output channels	7.2 channels
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	7
Number of HDMI outputs	2
Wi-Fi	Yes
