Denon AVR-X4400H Manual

Audio
Make audio-related settings.
Dialog Level Adjust
This setting adjusts the output level to clarify the dialogue output from the
center channel.
o
Dialog Level Adjust
Set whether to adjust the dialog level or not.
On:
Enables the adjustment of the dialog
level.
Off
(Default):
Disables the adjustment of the dialog
level.
o
Level
Adjusts the volume output from the center channel.
–12.0 dB – +12.0 dB (Default: 0.0 dB)
Subwoofer Level Adjust
This setting adjusts the volume level for the subwoofer.
o
Subwoofer Level Adjust
Set whether to adjust the subwoofer level.
On:
Enables the adjustment of the subwoofer
level.
Off
(Default):
Disables the adjustment of the subwoofer
level.
o
Subwoofer 1 Level / Subwoofer 2 Level
Adjusts the volume level for the Subwoofer 1 and Subwoofer 2.
–12.0 dB – +12.0 dB (Default: 0.0 dB)
Contents Connections Playback Settings Tips Appendix
170
Front panel Display Rear panel Remote Index

Denon AVR-X4400H Specifications

General

Display	-
ECO mode	Yes
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS:X, Dolby Atmos
Audio formats supported	ALAC, DSD, FLAC, WAV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Supported graphics resolutions	4096 x 2160
RS-232 ports	1
Connectivity technology	Wireless
HDMI in	8
Composite video in	4
Component video (YPbPr/YCbCr) in	2
Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	11.2
Input sensitivity	200 mV
Audio output channels	9.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	200 W
Power output per channel (20-20KHz@8 Ohm)	125 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	710 W
Number of HDMI outputs	3

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	13500 g
