Denon AVR-X4400H Manual

Manual Setup
Perform when setting the speakers manually or when changing settings
made in Audyssey
®
Setup.
0
If you add or remove a speaker after performing Audyssey
®
Setup, you
will no longer be able to select Audyssey MultEQ
®
XT32, Audyssey
Dynamic EQ
®
or Audyssey Dynamic Volume
®
. (v p. 180)
0
“Manual Setup” can be used without changing the settings. Please set if
necessary.
Amp Assign
Select the power amplifier usage method to match your speaker system.
o
Assign Mode
Select how to use the power amp.
You need to configure the detailed settings for the speaker
configuration in accordance with the selected mode. Select Assign
Mode configure the corresponding detailed settings.
11.1ch:
0
Setting to use the 9-channel power
amplifier in this unit and an external
power amplifier connected to PRE OUT
to play back up to 11.1-channels.
0
You can connect speakers for up to 11.1-
channels for MAIN ZONE.
Contents Connections Playback Settings Tips Appendix
215
Front panel Display Rear panel Remote Index

Denon AVR-X4400H Specifications

General

Display	-
ECO mode	Yes
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS:X, Dolby Atmos
Audio formats supported	ALAC, DSD, FLAC, WAV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Supported graphics resolutions	4096 x 2160
RS-232 ports	1
Connectivity technology	Wireless
HDMI in	8
Composite video in	4
Component video (YPbPr/YCbCr) in	2
Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	11.2
Input sensitivity	200 mV
Audio output channels	9.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	200 W
Power output per channel (20-20KHz@8 Ohm)	125 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	710 W
Number of HDMI outputs	3

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	13500 g
