Denon AVR-X520BT Service Manual

Jump to the target of a schematic
diagram connector
Click the Ref. No. of the target connector in the red
box around a schematic diagram connector.
•The screen jumps to the target connector.
•Pagemagnicationstaysthesameasbeforethe
jump.
CP401
CP106
v
ABOUT THIS MANUAL
Readthefollowinginformationbeforeusingtheservicemanual.
What you can do with this manual
Search for a Ref. No. (phrase)
(Ctrl+Shift+F)
YoucanusethesearchfunctioninAcrobatReaderto
searchforaRef.No.inschematicdiagrams,printed
wiringcircuitdiagrams,blockdiagrams,andparts
lists.
1.PressCtrl+Shift+Fonthekeyboard.
• TheSearchwindowappears.
2.EntertheRef.No.youwanttosearchforinthe
Searchwindow,andthenclicktheSearchbutton.
•Alistofsearchresultsappears.
3.Clickanitemonthelist.
•Thescreenjumpstothepageforthatitem,andthe
searchphraseisdisplayed.
Ctrl
Shift
F
3

Denon AVR-X520BT Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	90 W
Power output per channel (20-20KHz@8 Ohm)	70 W
HDMI in	5
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	-
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Ethernet LAN	No
AM band range	552 - 1611 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-HD, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7500 g
