Denon DCD-520AE Service Manual

16
2. FRONT PANEL ASSY
(1) Removing discs.
(2) Remove the door by pulling.
(3) Remove the screws.
CABINET TOP
FRONT PANEL ASSY

Proceeding :

Shooting direction: B
View from the bottom



Denon DCD-520AE Specifications

General

Audio formats supported	MP3, WMA
Signal-to-Noise Ratio (SNR)	105 dB
Total Harmonic Distortion (THD)	0.003 %
Built-in speaker(s)	No
CD-RW playback	Yes
Playback disc formats	CD audio
Device type	HiFi CD player
Product color	Black
Channel separation	100 dB
Headphone outputs	1
Headphone connectivity	6.3 mm
Display type	VFD
Power requirements	AC 230 V, 50 Hz
Power consumption (typical)	13 W

Weight and Dimensions

Depth	279 mm
Width	434 mm
Height	107 mm
Weight	4000 g
