Denon DCD-520AE Service Manual

94
CD PCB ASS'Y DCD720AE
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC11 943243101100D   *
IC12 943246100770D
  *
IC13 943235100530D
  *
IC21 943245006980S
 
IC22 943231101210D   *
IC23 943231101240D
  *
IC25 943239006810S
 
IC26 00D2623601907  
IC27 943239006810S  
IC31 943239006900S  
IC41 943248101250D   *
IC42 23671011050AS


DM
IC43 943239100710S  
IC51 943239100820D   *
 943215500020S
 
 943216500020S  
 943215500020S  
 943215500020S  
 00D2730464901  
 00D9430058908  
 943215500020S  
 943216500020S  
 943215500020S  
 943216500020S  
D101-106 00D2760717903  
D107 90M-HD201820R  
D108 00D2760717903  
 90M-HD201820R  
D151 00D2760717903  
D201-203 00D2760717903  
D401 90M-HD201820R  
RESISTORS GROUP
RN11 nsp
 
 nsp  
R103-105 nsp  
R107 nsp  
R108-112 nsp  
R113 nsp  
 nsp  
R116 nsp  
R117 nsp  
R118 nsp  
 nsp  
 nsp  
R125 nsp   
R125 nsp   
R127 nsp  
R129 nsp  
R130 nsp  
 nsp  
R146 nsp  
 nsp  
 nsp  
 nsp  
R158 nsp  
R160 nsp  
R191 nsp  
R192 nsp  
R199 nsp  
R201 nsp  
R202-204 nsp  
R207-210 nsp  
R211 nsp  

Denon DCD-520AE Specifications

General

Audio formats supported	MP3, WMA
Signal-to-Noise Ratio (SNR)	105 dB
Total Harmonic Distortion (THD)	0.003 %
Built-in speaker(s)	No
CD-RW playback	Yes
Playback disc formats	CD audio
Device type	HiFi CD player
Product color	Black
Channel separation	100 dB
Headphone outputs	1
Headphone connectivity	6.3 mm
Display type	VFD
Power requirements	AC 230 V, 50 Hz
Power consumption (typical)	13 W

Weight and Dimensions

Depth	279 mm
Width	434 mm
Height	107 mm
Weight	4000 g
