Denon DCD-520AE Service Manual

46
WAVEFORMS
①RFEQO
①RFEQO
①RFEQO
1.3 CD-RW（TCD-W000RM）Pla
y
1.2 CD-R（TCD-R000RM）Pla
y
1. DISC PLAY RF WAVEFORM
（
EYE-PATTERN
）
1.1 CD（TCD-784）Pla
y
2. DISC DETECTION
2.1 CD（TCD-784）DISC DETECTION
2.2 CD-R（TCD-R000RM）DISC DETEC
T
2.3 CD-RW（TCD-W000RM）DISC DETECTION
1V
200mV
2V
500Mv
2V
1V
2V
②RFO
󰴦FSMONIT
󰴧FOO
󰴨TEI
󰴩 TRO
󰴪FMO
󰴫DMO
1V
200mV
2V
500Mv
2V
1V
2V
1V
200mV
2V
500Mv
2V
1V
2V
②RFO
󰴦FSMONIT
󰴧FOO
󰴨TEI
󰴩 TRO
󰴪FMO
󰴫DMO
②RFO
󰴦FSMONIT
󰴧FOO
󰴨TEI
󰴩 TRO
󰴪FMO
󰴫DMO

Denon DCD-520AE Specifications

General

Audio formats supported	MP3, WMA
Signal-to-Noise Ratio (SNR)	105 dB
Total Harmonic Distortion (THD)	0.003 %
Built-in speaker(s)	No
CD-RW playback	Yes
Playback disc formats	CD audio
Device type	HiFi CD player
Product color	Black
Channel separation	100 dB
Headphone outputs	1
Headphone connectivity	6.3 mm
Display type	VFD
Power requirements	AC 230 V, 50 Hz
Power consumption (typical)	13 W

Weight and Dimensions

Depth	279 mm
Width	434 mm
Height	107 mm
Weight	4000 g
