Denon DCD-710AE Service Manual

5858
DCD-710AE
PARTS LIST OF P.W.B. UNIT
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate he following destinations.
E2 : Europe model E1C : China model
AUDIO/POWER PCB ASSY
Ref No. Part No. Part Name Remark Q'ty New
SEMICONDUCTORS GROUP
IC31 00D2623629002 IC AL24 PROCESSING DSP
CVI00D2623629002-DM
IC32 00D2622376903 IC HVITC74HCT7007F
IC33 90M-HC700560R IC VCO HVITC74LS628
IC34 00D2623077900 IC HEX INVERTER HVITC74VHCU04FT
IC35 00D2623601907 IC 2CH MULTIPLXER HVITC7WH157FU
IC36 00MHC1022521Z IC DUAL PLL SYNTHESIZER BVIBU2630FV-E2
IC37 00D2623199901 IC D FLIP FLOP CVITC7WH74FU
IC38 00D2623489909 IC INVERTER(CMOS) CVITC7WHU04FU
IC39 00D2623332904 IC D/A CONVERTER HVIPCM1791ADBR
IC40 00D2631243001 I.C REGULATOR CVIKIA78D33PI
IC41,42 00D2630896909 IC OP AMP HVINJM2068MDTE1
IC43 943239006810S IC SIGNAL INVERTER (USV) CVIKIC7SH04FU
IC71 00D9430194706 REMOCON SENSOR CRVKSM603TH2E
IC72 00MHC10200090 I.C HEADPHONE HVINJM4556AL
IC81 00D2631100018 I.C REGULATOR +6V HVIKIA7806API
IC82 00MHC3990699F I.C -6V REGULATOR (TO220IS) CVIKIA7906PI
IC83 00D2631100018 I.C REGULATOR +6V HVIKIA7806API
IC84 00D2631285001 IC REGULATOR CVISI8001FFE
IC85 00D2631243001 IC REGULATOR CVIKIA78D33PI
IC86 00D2622944946 IC REGULATOR (3.3V SMD ) BVIBA33BC0FP
Q301,302 00D2730477901 CHIP TR HVTKRA107S
Q303,304 00D2730460905 CHIP TR HVTKTC2875B
Q307 00D9630121606 TR KRC107S HVTKRC107S
Q701,702 00D2690184907 CHIP TR HVTKRA102S
Q703-706 00M-HX900010R CHIP TR (MUTE) HVTKTD1304T
Q711,712 00D2690192902 CHIP TR HVTKRC102S
z Q801 943219006820S TR CVTKTC1027YT
z Q802 00D2730464901 CHIP TR HVTKTC3875SYRTK
Q805,806 00D2730464901 CHIP TR HVTKTC3875SYRTK
D302,303 00D9430182502 DIODE 1N4003 CVD1N4003T
D701 00D9430198100 LED SML1216W HVDSML1216W
D704-706 00D2760717903 DIODE 1SS355T HVD1SS355T
D707 943209006830S DIODE ESD PROTECTION USC CVDPG05GBUSCRTKP
D708 00D2760717903 DIODE 1SS355T HVD1SS355T
D709 943209006830S DIODE ESD PROTECTION USC CVDPG05GBUSCRTKP
D710 00D2760717903 DIODE 1SS355T HVD1SS355T
D712 00D2760717903 DIODE 1SS355T HVD1SS355T
D713 00D2760717903 DIODE 1SS355T HVD1SS355T
D800 943204006840S DIODE , SCHOTTKY (40V,3A, DO-214AC) CVDSS34SR
D801-804 00D9430182502 DIODE 1N4003 CVD1N4003T
D805,806 00D9430086404 DIODE 1SS133T-77 HVD1SS133MT
z D807 90M-HE200390R BRIDGE DIODE HVDGBJ1006
D808,809 00D9430086404 DIODE 1SS133T-77 HVD1SS133MT
D810,811 00D9430182502 DIODE 1N4003 CVD1N4003T
D812 00D9430087102 DIODE MTZJ20B 1/2W HVDMTZJ20BT
D813 00D2760762916 DIODE MTZJ27B 1/2W HVDMTZJ27BT
D814 00D2760760905 DIODE MTZJ3.6B 1/2W HVDMTZJ3.6BT
D815 00D2760717903 DIODE 1SS355T HVD1SS355T
D816 943204006850S DIODE , SCHOTTKEY BARRIER HK HVDRB160L60TE25
D818-821 943204006850S DIODE , SCHOTTKEY BARRIER HK HVDRB160L60TE25

Denon DCD-710AE Specifications

General

Audio system	stereo
Audio formats supported	MP3, WMA
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.0025 %
CD-RW playback	Yes
Playback disc formats	CD audio
CD changer	No
Device type	HiFi CD player
Product color	Silver
Disc playback modes	Programming
Number of optical discs	1 discs
Display type	VFD
Volume control	Digital
Programmable tracks	25
Headphone connectivity	6.3 mm
USB 2.0 ports quantity	1
Power requirements	230V AC, 50Hz
Power consumption (typical)	22 W

Weight and Dimensions

Depth	279 mm
Width	434 mm
Height	107 mm
Weight	4200 g
