Denon DCD-710AE Service Manual

6363
DCD-710AE
MAIN PCB ASSY
Ref No. Part No. Part Name Remark Q'ty New
SEMICONDUCTOR GROUP
IC11 943243006920D MCU IC(512K,LQFP-100P)
CVIANAM1494C *
IC13 943249006970S EEPROM (4K,SO8-8P)
CVIM95040-WMN6TP
IC14 943239006900S 5-CH MOTOR DRIVE IC (WITH REG,SSOP-28P) CVIIP4001CRLTF
IC15 943243006930D USB DECODER FLASH IC(100PIN, QFP) CVIANAM1495C *
IC16 236710022502S
CP CHIP IC(MF134IS2161,20P,FROM MARANTZ) CVI236710022502S_M
IC17 943245006980S CD DSP IC(SERVO,AMPLIFIER,DSP,LQFP-80P) CVITC94A92FG *
IC18 00D2623601907 2CH MULTIPLXER IC
HVITC7WH157FU
IC19 943239006810S SIGNAL INVERTER IC(USV) CVIKIC7SH04FU
IC20 90M-HC900160R IC LM1117S15 REG. (SOT-223) CVIKIA1117S15
Q202 00D9430058908 CHIP TR HVTKTA1504SYRTK
D201 00D9430060404 SCHOTTKEY BARRIER DIODE HVDRB160L60TE25
D202 00D9430060404 SCHOTTKEY BARRIER DIODE HVDRB160L60TE25
D206 943209001080S CHIP DIODE CVD1SS355T
CAPACITORS GROUP
C101,102 nsp CHIP CAP
CCUS1H104KC
C103-105 nsp CHIP CAP CCUS1H103KC
C106 nsp CHIP CAP CCUS1H102KC
C107,108 nsp CHIP CAP CCUS1H104KC
C109 nsp CHIP CAP CCUS1H103KC
C110 nsp CHIP CAP CCUS1H180JA
C111 nsp CHIP CAP CCUS1H220JA
C112 nsp CHIP CAP CCUS1H104KC
C113,114 nsp CHIP CAP CCUS1H103KC
C115-117 nsp CHIP CAP CCUS1H104KC
C118 nsp CHIP CAP CCUS1A105KC
C151 nsp CHIP ELECT CAP HCEC0JRV2101T
C201 nsp CHIP CAP CCUS1H222KC
C202,203 nsp CHIP CAP CCUS1H104KC
C204 nsp CHIP CAP CCUS1H103KC
C205 nsp CHIP CAP CCUS1H472KC
C206 nsp CHIP CAP CCUS1H104KC
C207 nsp CHIP CAP CCUS1H153KC
C208 nsp CHIP CAP CCUS1H104KC
C210,211 nsp CHIP CAP CCUS1H104KC
C213 nsp CHIP CAP CCUS1H104KC
C214 nsp CHIP CAP CCUS1H333KC
C215 nsp CHIP CAP CCUS1H562KC
C216 nsp CHIP CAP CCUS1H471JA
C217 nsp CHIP CAP CCUS1H473KC
C219 nsp CHIP CAP CCUS1H473KC
C220-222 nsp CHIP CAP CCUS1H104KC
C223 nsp CHIP CAP CCUS1H103KC
C224 nsp CHIP CAP CCUS1H470JA
C225 nsp CHIP CAP CCUS1H153KC
C226 nsp CHIP CAP CCUS1H103KC
C227 nsp CHIP CAP CCUS1H471JA
C231 nsp CHIP CAP CCUS1H102KC
C232,233 nsp CHIP CAP CCUS1H104KC
C234 nsp CHIP CAP CCUS1H102KC
C235 nsp CHIP CAP CCUS1H104KC
C236 nsp CHIP CAP CCUS1H102KC
C237 nsp CHIP CAP CCUS1H104KC
C238 nsp CHIP CAP CCUS1H102KC
C239 nsp CHIP CAP CCUS1H103KC
C240 nsp CHIP CAP CCUS1H104KC
C243-247 nsp CHIP CAP CCUS1H104KC

Denon DCD-710AE Specifications

General

Audio system	stereo
Audio formats supported	MP3, WMA
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.0025 %
CD-RW playback	Yes
Playback disc formats	CD audio
CD changer	No
Device type	HiFi CD player
Product color	Silver
Disc playback modes	Programming
Number of optical discs	1 discs
Display type	VFD
Volume control	Digital
Programmable tracks	25
Headphone connectivity	6.3 mm
USB 2.0 ports quantity	1
Power requirements	230V AC, 50Hz
Power consumption (typical)	22 W

Weight and Dimensions

Depth	279 mm
Width	434 mm
Height	107 mm
Weight	4200 g
