Denon DHT-1312XP User Manual

101
HDMI P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC11 943236012460S IC HDMITransceiver(LQFP-144P) CVIADV7623BSTZ *
IC14 943248100030S I.C, MX25L8006EM2I CVIANAM1571AV *
IC15 943239010400S REGULATOR IC NJM2845DL133 CVINJM2845DL133
IC16 nsp IC EX3AV CVIEX3AV
Q101 943215500020S TR RT1P141C CVTRT1P141C *
Q102 943216500040S TR RT1N241C CVTRT1N241C *
Q103 943215500020S TR RT1P141C CVTRT1P141C *
Q104 943216500040S TR RT1N241C CVTRT1N241C *
Q105 943215500020S TR RT1P141C CVTRT1P141C *
Q106 943216500040S TR RT1N241C CVTRT1N241C *
Q107 943215500020S TR RT1P141C CVTRT1P141C *
Q108 943216500040S TR RT1N241C CVTRT1N241C *
RESISTORS GROUP
R122 nsp RES,CHIP(1608/1%/1.6Kohm) CRJ10DF1601T
R123 nsp RES,CHIP(1608/1%/2Kohm) CRJ10DF2001T
R143,144 nsp RES,CHIP1005,1K0,1/16W,1% CRJ06IF1001T
R168 nsp RES,CHIP(68K / 1% / 1005 size) CRJ06IF6802T
R169 nsp RES,CHIP(39K / 1% / 1005 size) CRJ06IF3902T
R170 nsp RES,CHIP(150K / 1% / 1005 size) CRJ06IF1503T
RN11,13 nsp RESNETWORK CHIP (33ohm 1/16W) CRJ064IJ330T
CAPACITORS GROUP
C101-129 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C130 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C131 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C132 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C133 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C134 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C135 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C136 nsp CHIP CAP 1UF 10V CCUS1A105KC
C138 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C139 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C140 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C141 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C144 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C145 nsp CHIP CAP 47PF 50V CCUS1H470JA
C146 nsp CHIP CAP 47PF 50V CCUS1H470JA
C147 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C148 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C149 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C150 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C161 nsp CHIP CAP 1UF 10V CCUS1A105KC
C162,163 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C164 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C165 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C166 nsp CHIP CAP 0.22UF 16VK CCUS1C224KC
C167 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C171 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C172 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C174 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C175 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C176 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C178 nsp CHIP CAP 0.015UF 25V CCUI1E153KC
C179 nsp CHIP CAP 15PF 50V CCUS1H150JA
C180 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C334 nsp CAP,CHIP(2012,10V/22uF) CCUC1A226KC

Denon DHT-1312XP Specifications

General

Product color	Black
Volume control	Rotary
RMS rated power	110 W
Recommended usage	Home theatre
Remotely operated	Yes
Audio output channels	5.1 channels
Amplification device type	AV receiver
Amplifier frequency range	10 - 100000 Hz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.08 %
Amplification device form factor	Stand-alone
Amplifier dimensions (W x D x H)	434 x 382 x 162 mm
Satellite speaker type	-
Satellite speaker weight	800 g
Number of satellite speakers	2
Satellite speakers RMS power	- W
Satellite speaker frequency range	150 - 20000 Hz
Satellite speaker dimensions (WxDxH)	105 x 150 x 200 mm
Center speaker dimensions (WxDxH)	200 x 150 x 105 mm
Subwoofer weight	11000 g
Subwoofer frequency range	35 - 150 Hz
Subwoofer dimensions (WxDxH)	250 x 420 x 387 mm
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Headphone outputs	1

Weight and Dimensions

Set weight	8900 g
