PARTS LIST OF PACKING & ACCESSORIES (for AVR-1312)
z
Parts indicated by "nsp" on this table cannot be supplied.
z
Parts indicated by the "
★
" mark are not illustrated in the exploded view.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
E1C : China model EA : Australia model
BK : Black model SP : Premium Silver model
Ref.No. Part No. Part Name Remarks Q'ty New
1 nsp POLY BAG CPP1A081X 1
z
2 90M-YC000780R POWER CORD E3 CJA523FBYA 1
z
2 90M-ZC000320R POWER CORD E2 CJA2B054Z 1
z
2 90M-ZC000430R POWER CORD EA HJA2S084Z 1 *
z
2 90M-YC000850R POWER CORD E1C CJA2N047ZA 1
3 943533012540D SNOW PAD(L) CPS1A909 1 *
4 943533100040D SNOW PAD(R) CPS1A910 1 *
5 - INSTRUCTION MANUAL ASS'Y
5-1 nsp BATTERY(AAA) CABR03PPB 2
5-2 352010015007D INST. MANUAL(E3 CD-ROM) E3 CFTAVR1312ZA 1 *
5-2 352010016000D INST. MANUAL(E2 CD-ROM) E2,EA CFTAVR1312YA 1 *
5-2 352010035001D INST. MANUAL(E1C CD-ROM) E1C CFTAVR1312XA 1 *
5-3 nsp POLY BAG(MANUAL) CPB1A197Z 1
★
5-4 nsp BARCODE LABEL(MANUAL) CQB1A971 1
5-5 nsp S.S LIST CQE1A226P 1
5-6 nsp WARRANTY CARD E3 CQE1A224R 1
5-7 nsp CARD FOR CHINA INDENTIFICATION E1C CQE1A450Z 1
5-8 nsp WARRANTYCARD CHINA E1C CQE1A473Z 1
5-9 542110051003D QUICK MANUAL(E3) E3 CQX1A1612Z 1 *
5-9 542110052006D QUICK MANUAL(E2) E2,EA CQX1A1612Y 1 *
5-9 542110061000D QUICK MANUAL(E1C) E1C CQX1A1612X 1 *
5-10 90M-ZA000230R FM 1 POLANT(UL) E3 CSA1A019Z 1
5-10 00D9430113403 FM 1 POLE ANT. BKE2,EA,E1C CSA1A018Z 1
5-11 943116009500S AM LOOP ANT CSA1A032Z 1
6 307010089008D REMOCONASS'Y(RC-1158) CARTAVR1312 1 *
7 943531012550D OUTCARTON BOX E3,BKE1C CPG1A942Z 1 *
7 943531012560D OUTCARTON BOX E2,EA CPG1A942Y 1 *
7 943531100020D OUTCARTON BOX SPE1C CPG1A942X 1 *
8 nsp CONTROL LABEL CQB1A993Z 1
9 nsp COLOR LABEL SPE1C CQB1A676 2
★
10 nsp ANGLE SIDEBAR CPW1A011 1
★
11 nsp CLAMPER ARM CHE154 1
★
12 nsp LABEL BARCODE(SET) CQB1A978 1
★
13 nsp PALLET CPW1A043 1
★
14 nsp PESHEET CPE1D001 1
★
15 nsp RIBON BARCODE CQS1A001 1
