Denon DHT-1312XP User Manual

64
PARTS LIST OF EXPLODED VIEW
z
Parts indicated by "nsp" on this table cannot be supplied.
z
P.W.B. ASS'Y indicated by "nsp" on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts list and order replacement parts.
z
Parts indicated by the "
★
" mark are not illustrated in the exploded view.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
E1C : China model EA : Australia model
BK : Black model SP : Premium Silver model
Ref.No. Part No. Part Name Remarks Q'ty New
C3' nsp FRONT PCB ASS'Y E3 COP12381G 1 *
C3' nsp FRONT PCB ASS'Y E2,EA,E1C COP12381H 1 *
C1 - PORTABLE IN PCB
C2 - VOLUME PCB
C3 - FRONT PCB
C4 - HEADPHONE PCB
C5 - POWER PCB
C7 - REGULATOR PCB
C9 - WIRE SUPPORT
C6' nsp MAIN PCB ASS'Y E3 COP12396B 1 *
C6' nsp MAIN PCB ASS'Y E2,EA COP12396C 1 *
C6' nsp MAIN PCB ASS'Y E1C COP12396D 1 *
C6 - MAIN PCB
C8 - WIRE SUPPORT PCB
C10 nsp INPUT PCB ASS'Y E3 COP12375B 1 *
C10 nsp INPUT PCB ASS'Y E2,EA COP12375C 1 *
C10 nsp INPUT PCB ASS'Y E1C COP12375D 1 *
C11 943633012250D HDMI PCB ASS'Y E3 COP12376B 1 *
C12 nsp AC CORD BUSHING E3,E1C CHR1A028 1
C13 00MYJ04002640
AC RECEPTACLE
(15A/250V,R-301,B21)
E2,EA CJJ8A006ZW 1
z
C14 943101009640D TRANS POWER E3 CLT5U042YU 1
z
C14 943101009650D TRANS POWER E2,EA CLT5U042YE 1
z
C14 943101009660D TRANS POWER E1C CLT5U042YH 1
z
C15 90M-YC000780R POWER CORD E3 CJA523FBYA 1
z
C15 90M-ZC000320R POWER CORD E2 CJA2B054Z 1
z
C15 90M-ZC000430R POWER CORD EA HJA2S084Z 1
z
C15 90M-YC000850R POWER CORD E1C CJA2N047ZA 1
P1 943412009840D VOLUME KNOB BK CBN1A249 1
P1 943412009850D VOLUME KNOB SP CBN1A249C73 1
P2 943419100020D RCA COVER BK CGR1A510B28 1 *
NOTE :
Please change the destination-resistors when changing 1312E3 (943633012250D) to other destination.
Please refer to destination-resistors page 60 .
(SCHEMATIC DIAGRAMS : 6/7)
R916 R917
1312 E3 10K 4.7K
1312 E2/EA 10K OPEN
1312 E1C 10K 10K

Denon DHT-1312XP Specifications

General

Product color	Black
Volume control	Rotary
RMS rated power	110 W
Recommended usage	Home theatre
Remotely operated	Yes
Audio output channels	5.1 channels
Amplification device type	AV receiver
Amplifier frequency range	10 - 100000 Hz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.08 %
Amplification device form factor	Stand-alone
Amplifier dimensions (W x D x H)	434 x 382 x 162 mm
Satellite speaker type	-
Satellite speaker weight	800 g
Number of satellite speakers	2
Satellite speakers RMS power	- W
Satellite speaker frequency range	150 - 20000 Hz
Satellite speaker dimensions (WxDxH)	105 x 150 x 200 mm
Center speaker dimensions (WxDxH)	200 x 150 x 105 mm
Subwoofer weight	11000 g
Subwoofer frequency range	35 - 150 Hz
Subwoofer dimensions (WxDxH)	250 x 420 x 387 mm
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Headphone outputs	1

Weight and Dimensions

Set weight	8900 g
