Denon DHT-1312XP User Manual

97
INPUT P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC60 943231010390S REGULATOR IC KIA7805BPI CVIKIA7805BPI
IC61 943235003810S IC R2A15218FP CVIR2A15218FP
IC62-65 00D2631289900 IC AZ4580MTR-E1 CVIAZ4580MTR-E1
IC66,67 00D2630934900 IC BA4510F HVIBA4510F
IC68 943231010390S REGULATOR IC KIA7805BPI CVIKIA7805BPI
IC69 943239010400S REGULATOR IC NJM2845DL133 CVINJM2845DL133
IC71 90M-HC109700R IC NJM2595MTE1 CVINJM2595MTE1
IC72 00MHC1010455Y IC MM1511XNRE HVIMM1511XNRE
IC74 00D2631099006 REGULATOR IC KIA7905PI CVIKIA7905PI
IC81 943245010410S IC CS497024CVZ CVICS497024CVZ
IC82 943246010420S IC, SST25VF080B-50-4C-S2AF CVIANAM1530AV
IC83 943246012710S IC, M12L16161A-5TG CVIM12L16161A5TG2K *
IC84 90M-HC110090R IC CS42528-CQ HVICS42528-CQ
IC85 00D2623198902 IC C74VHC157FT HVITC74VHC157FT
IC91 943243100020S IC IT5CN5(512KB/32KB,LQFP100P) CVIANAM1558AV *
IC92 943246010440S IC M24C32WMN6TP CVIM24C32WMN6TP
IC93 00D2623410907 IC TC74VHCT08AFT HVITC74VHCT08FT
IC94 00D2623444902 IC TC74VHC08FT CVITC74VHC08FT
IC95 943239010400S REGULATOR IC NJM2845DL133 CVINJM2845DL133
IC96 943234010450S IC BD5225G CVIBD5225G
Q901 943214500020S TR 2SC3052 CVT2SC3052 *
Q903 943214500020S TR 2SC3052 CVT2SC3052 *
D601,602 943209001080S DIODE 1SS355T CVD1SS355T
D605,606 00D9430196306 DIODE ZJ7.5B CVDZJ7.5BT
D903 943209001080S DIODE 1SS355T CVD1SS355T
RESISTORS GROUP
R736,737 nsp METAL OXID EFILM RES(68OHM 1W) CRG1SANJ680RT
R761-764 nsp CHIP RES1%75OHM CRJ10DF75R0T
R766 nsp CHIP RES(82OHM 1%) CRJ10DF82R0T
R805 nsp CHIP RES(1.37KOHM 1/16W 1% 1608) CRJ10DF1371T
R839 nsp CHIP RES(5.1K 1%) CRJ10DF5101T
R916 nsp CHIP RES,10K OHM 1/10W J CRJ10DJ103T
R917 nsp CHIP RES,4.7K OHM 1/10W J E3 CRJ10DJ472T
R917 nsp CHIP RES,10K OHM 1/10W J E1C CRJ10DJ103T
R958 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
RN61 nsp CHIP RES(100OHM 5% 1608X4) CRJ104DJ101T
RN80 nsp CHIP RES(10KOHM 5% 1608X4) CRJ104DJ330T
RN81,82 nsp CHIP RES(10KOHM 5% 1608X4) CRJ104DJ103T
RN83-90 nsp CHIP RES(10KOHM 5% 1608X4) CRJ104DJ330T
RN91,92 nsp CHIP RES(100OHM 5% 1608X4) CRJ104DJ101T
RN93 nsp CHIP RES(10KOHM 5% 1608X4) CRJ104DJ103T
CAPACITORS GROUP
C603 nsp CHIP CAP 8200UF 50V CCUS1H822KC
C604 nsp CHIP CAP 8200UF 50V CCUS1H822KC
C605 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C606 nsp CHIP CAP 3900PF 50V K CCUS1H392KC
C607 00D9430103808 ELECT CAP 470UF 10V CCEA1AH471T
C610,611 nsp CHIP CAP 100PF 50V J CCUS1H101JA
C612 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C613,614 nsp CHIP CAP 100PF 50V J CCUS1H101JA
C619,620 nsp CHIP CAP 220PF 50V CCUS1H221JA
C623,624 nsp CHIP CAP 220PF 50V CCUS1H221JA
C627,628 nsp CHIP CAP 220PF 50V CCUS1H221JA
C629 00D9430062101 ELECT CAP 100UF 16V CCEA1CH101T
C636-639 nsp ELECT CAP 47UF 16V CCEA1CH470T
C640 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
C641 nsp ELECT CAP 47UF 16V CCEA1CH470T
NOTE :
When update Firmware,
please conrm a last
version in SDI.
Use the service board
after updating it.

Denon DHT-1312XP Specifications

General

Product color	Black
Volume control	Rotary
RMS rated power	110 W
Recommended usage	Home theatre
Remotely operated	Yes
Audio output channels	5.1 channels
Amplification device type	AV receiver
Amplifier frequency range	10 - 100000 Hz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.08 %
Amplification device form factor	Stand-alone
Amplifier dimensions (W x D x H)	434 x 382 x 162 mm
Satellite speaker type	-
Satellite speaker weight	800 g
Number of satellite speakers	2
Satellite speakers RMS power	- W
Satellite speaker frequency range	150 - 20000 Hz
Satellite speaker dimensions (WxDxH)	105 x 150 x 200 mm
Center speaker dimensions (WxDxH)	200 x 150 x 105 mm
Subwoofer weight	11000 g
Subwoofer frequency range	35 - 150 Hz
Subwoofer dimensions (WxDxH)	250 x 420 x 387 mm
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Headphone outputs	1

Weight and Dimensions

Set weight	8900 g
