Denon DP-300F Service Manual

9
DP-300F
PARTS LIST OF EXPLODED VIEW
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model (Black) BKE2 : Europe model(Black) SPE2 : Europe model(P.Silver)
K(JP) : Japan model(Black) SP(JP) : Japan model(P.Silver)
Ref. No. nsp Part No. Part Name Remarks Q'ty New
1 00D 941 0012 401 Cam Gear Ass'y 701-SL24F-192 1
2 - Cam Gear control Assy 703-SL24F-050 1
3 - Cam Gear 100-SL24F-248 1
4 - Friction Link 300-SL24F-130 1
5 - Actuating Link 300-SL24F-131 1
6 nsp 00D 941 0008 208 Spring 603-SL24F-077 1
7 - Washer 606-F200-006 1
8 - CS Washer(3mm) 606-F200-013 2
9 - E-Ring(2mm) 606-B300-029 1
10 - Washer 606-SL24F-057 2
11 00D 941 0037 509 Hinge Ass'y 701-300-3708 2 *
12 - Speed Bracket Ass'y 701-300-3629 1 *
13 - Select Plate Ass'y 701-300-3630 1 *
14 00D 941 0037 606 Size Knob E3,BKE2,K(JP) 701-300-3631 1 *
14 00D 941 0037 703 Size Knob SPE2,SP(JP) 701-300S-3631 1 *
180 00D 941 0040 004 Tonearm Lifter Ass'y E3,BKE2,K(JP) 701-300-3702 1 *
180 00D 941 0040 703 Tonearm Lifter Ass'y SPE2,SP(JP) 701-300S-3702 1 *
147 - Rubber for Tonearm Lifter 604-300-366 1 *
15 - Tonearm Lifter Ass'y E3,BKE2,K(JP) 701-300-3632 1 *
15 - Tonearm Lifter Ass'y SPE2,SP(JP) 701-300S-3632 1 *
181 00D 941 0040 101 Handle Ass'y 701-300-3701 1 *
16 - Handle Ass'y 701-300-3633 1 *
113 - Handle Knob 200-300-494 1 *
17 - Pendulum Ass'y 701-300-3668 1 *
18 - Pendulum (S) 100-300-2394 1 *
19 - Spring 603-SL24F-066 1
21 00D 941 0037 800 Bottom Board 100-300-2378 1 *
22 - Bottom Plate 300-300-1359 1 *
23 - Screw 602-DJ3000-273 8
24 00D 941 0036 704 Counter Weight Adjustor Ass'y E3,BKE2,K(JP) 72-300-054 1 *
24 00D 941 0036 801 Counter Weight Adjustor Ass'y SPE2,SP(JP) 72-300S-055 1 *
25 - Indicator E3,BKE2,K(JP) 100-300-2404 1 *
25 - Indicator SPE2,SP(JP) 100-300S-2404 1 *
26 - Counterweight Ring E3,BKE2,K(JP) 200-300-502 1 *
26 - Counterweight Ring SPE2,SP(JP) 200-300S-502 1 *
27 00D 941 0037 907 Cartridge 402-300F-093 1 *
27-1 00D DSN85 Stylus DSN-85 1 *
178 00D 941 0039 701 Lifter Ass'y E3,BKE2,K(JP) 701-300-3694 1 *
178 00D 941 0039 808 Lifter Ass'y SPE2,SP(JP) 701-300S-3693 1 *
28 - Shaft 200-300-496 1 *
106 - Lifter E3,BKE2,K(JP) 100-300-2396 1 *
106 - Lifter SPE2,SP(JP) 100-300S-2396 1 *
127 nsp 00D 941 0007 209 Spring 603-MD26-059 1
160 - Screw(2*10,JMB BLACK) 602-MD26-081 1
30 00D 941 0012 304 Center & Pinion Ass'y 703-F703-253 1
31 - Shaf & Holder Ass'y 703-SL24F-051B 1
32 - Small Gear 100-SL24F-244 1
33 - Center shaft 200-SL24F-105A 1
34 - Spindle Ring 200-SL24F-123 1
35 - Screw 602-SL24F-093 1
36 - Steel Ball 607-B600-002 1
37 - Return Link Ass'y 703-300-992 1 *
2
2
2
2
2
2

Denon DP-300F Specifications

General

Type	Belt-drive audio turntable
Interface	PHONO
Product color	Black, Silver
Wow & flutter	0.1 %
Nominal speeds	33 1/3, 45 RPM
Stylus pressure	4 g
Signal-to-Noise Ratio (SNR)	60 dB
Arm length	221.5 mm
AC adapter frequency	60 Hz
AC adapter input voltage	80 - 260 V
Power consumption (typical)	2 W
Frequency range	20 - 20000 Hz

Weight and Dimensions

Weight	5500 g
Product dimensions (WxHxD)	434 x 381 x 122 mm
